XSAV12373TT Schneider
XSAV12373TT Schneider
Opis
Rot. monitoring - M30 - Sn10mm - 120..3000c/mn - 12..48VDC - cable 2m
Tehnične lastnosti
| Glavno | |
| Serija izdelka | OsiSense XS |
| Aplikacija naprave | rotation monitoring |
| [Us] Nazivna napajalna npetost | 12...48 V DC with reverse polarity protection |
| size | 81 mm |
| Material | metal |
| IP degree of protection | IP67 conforming to IEC 60529 |
| sensor design | cylindrical M30 |
| series name | Application |
| body type | fixed |
| electrical connection | cable |
| enclosure material | nickel plated brass |
| discrete output type | PNP |
| discrete output function | 1 NC |
| type of output signal | discrete |
| Dolžina kabla | 2 m |
| sensor name | XSA |
| wiring technique | 3-wire |
| [Sn] nominal sensing distance | 10 mm |
| sensor type | inductive proximity sensor |
| detector flush mounting acceptance | flush mountable |
| switching capacity in mA | <= 200 mA with overload and short-circuit protection |
| output circuit type | DC |
| Komplementarno | |
| Višina | 30 mm |
| Teža izdelka | 0.3 kg |
| Poraba toka | 0...15 mA no-load |
| Omejitve napajalne napetosti | 10-58 V DC |
| thread type | M30 x 1.5 |
| maximum voltage drop | <1.8 V (closed) |
| length | 81 mm |
| Označevanje | CE |
| repeat accuracy | 3% of Sr |
| switching frequency | <= 800 Hz |
| sensing range | > 8...15 mm |
| differential travel | 3...15% of Fr |
| wire insulation material | PvR |
| detection face | frontal |
| cable composition | 3 x 0.34 mm² |
| front material | PPS |
| status LED | output state: 1 LED (red) |
| threaded length | 57 mm |
| operating zone | 0-8 mm |
| run-up delay at power-up | 9 s standard |
| adjustable frequency range | 120-3000 cyc/mn |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-85 °C |
| Temperatura okoliškega zraka za skladiščenje | -40-85 °C |
| Certifikati izdelkov | CCC UL CSA |
