XSDT023319 Schneider
XSDT023319 Schneider
Opis
inductive sensor XSD 80x80x40 - plastic - Sn40mm - 24..240VAC - terminals
Tehnične lastnosti
| Glavno | |
| Serija izdelka | OsiSense XS |
| [Us] Nazivna napajalna npetost | 12...240 V AC |
| size | 40 mm |
| IP degree of protection | IP67 |
| sensor design | form 80 x 80 x 40 |
| series name | general purpose |
| body type | fixed |
| electrical connection | screw-clamp terminals |
| product specific application | - |
| enclosure material | plastic |
| discrete output function | 1 NO or 1 NC programmable |
| type of output signal | discrete |
| sensor name | XSD |
| wiring technique | 2-wire |
| [Sn] nominal sensing distance | 40 mm |
| sensor type | inductive proximity sensor |
| Komplementarno | |
| Višina | 100 mm |
| Teža izdelka | 0.48 kg |
| Širina | 80 mm |
| Globina | 40 mm |
| Material | plastic |
| cable entry | 1 entry tapped for Pg 13.5 cable gland |
| Označevanje | CE |
| switching frequency | <= 10 Hz |
| sensing range | > 15...40 mm |
| detection face | frontal |
| front material | plastic |
| switching capacity in mA | 5...500 mA |
| detector flush mounting acceptance | non flush mountable |
| output circuit type | AC |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| Certifikati izdelkov | CCC |
