XCKD3911P16EX Schneider Electric
XCKD3911P16EX Schneider Electric
Opis
limit switch XCKD - plunger with elastomer boot - 2NC + NO - ATEX/IECEx
Tehnične lastnosti
| Glavno | |
| Serija izdelka | OsiSense ATEX D |
| Izdelek ali sestavni del | limit switch |
| Kratko ime naprave | XCKD |
| head type | plunger head |
| type of operator | spring return plunger metal with elastomer boot |
| Material | metal |
| IP degree of protection | IP66 conforming to IEC 60529 IP67 conforming to IEC 60529 |
| contacts type and composition | 2 NC + 1 NO |
| contact operation | snap action |
| movement of operating head | linear |
| fixing mode | by the body |
| sensor design | compact |
| type of approach | vertical approach, 1 direction |
| series name | standard format |
| body type | fixed |
| number of poles | 3 |
| electrical connection | screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 0.75 mm² |
| positive opening | with |
| number of steps | 1 |
| switch actuation | on end |
| contacts insulation form | Zb |
| cable entry number | 1 tapped entry for M16 x 1.5 cable gland (included) 4-8 mm |
| maximum actuation speed | 0.5 m/s |
| minimum force for tripping | 15 N |
| Komplementarno | |
| Višina | 65-65 mm |
| [Ui] Nazivna izolacijska trdnost | 300 V conforming to UL 508 400 V (pollution degree 3) conforming to IEC 60947-1 300 V conforming to CSA C22.2 No 14 |
| electrical durability | 5000000 cycles, DC-13, inductive load type, 120 V, 2 W, operating rate <3600 cyc/mn, load factor: 0.5 , DC conforming to IEC 60947-5-1 appendix C 5000000 cycles, DC-13, inductive load type, 24 V, 4 W, operating rate <3600 cyc/mn, load factor: 0.5 , DC conforming to IEC 60947-5-1 appendix C 5000000 cycles, DC-13, inductive load type, 48 V, 3 W, operating rate <3600 cyc/mn, load factor: 0.5 , DC conforming to IEC 60947-5-1 appendix C |
| mechanical durability | 15000000 cycles |
| Kompatibilnostna koda | XCKD |
| Širina | 31 mm |
| Globina | 30 mm |
| short-circuit protection | 6 A cartridge fuse, type gG |
| Označevanje | II2 D-Ex tb IIIC T85°C Db IP66/67 |
| [Ithe] conventional enclosed thermal current | 6 A AC |
| maximum resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3 |
| minimum actuation speed | 0.01 m/min |
| body material | zamak |
| contact code designation | B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to EN 60947-5-1 B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to IEC 60947-5-1 appendix A R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to EN 60947-5-1 R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to IEC 60947-5-1 appendix A |
| head material | zamak |
| positive opening minimum force | 45 N |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -20-60 °C |
| Certifikati izdelkov | INERIS 04ATEX0014X IEC-Ex INE 17.0020X |
| Standardi | EN/IEC 60079-31 EN/IEC 60079-0 |
| Odporno proti udarcu | 50 gn for 11 ms conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| electrical shock protection class | class I conforming to IEC 61140 class I conforming to NF C 20-030 |
| Zaščitna obdelava | TC |
| directives | 2014/34/EU - ATEX directive |
| dust zone | zone 21 - 22 |
