RXG15ED Schneider
RXG15ED Schneider
Opis
Interface plug-in relay, 10 A, 1 CO, clear cover, 48 V DC
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Zelio Relay |
| Izdelek ali sestavni del | plug-in relay |
| Kratko ime naprave | RXG |
| contacts type and composition | 1 C/O |
| series name | interface relay |
| Komplementarno | |
| Teža izdelka | 0.018 kg |
| [Ui] Nazivna izolacijska trdnost | 250 V conforming to IEC 300 V conforming to CSA 300 V conforming to UL |
| electrical durability | 100000 cycles for NO resistive load at 55 °C 100000 cycles for NC resistive load at 55 °C |
| mechanical durability | 10000000 cycles |
| [Uimp] rated impulse withstand voltage | 6 kV 1.2/50 µs |
| device presentation | complete product |
| contacts material | silver alloy (AgSnO2In2O3) |
| [Ie] rated operational current | 10 A at 30 V (DC) conforming to UL 10 A at 30 V (DC) conforming to IEC 10 A at 250 V (AC) conforming to IEC 10 A at 250 V (AC) conforming to UL |
| [Uc] control circuit voltage | 48 V DC |
| [Ithe] conventional enclosed thermal current | 10 A at -40-55 °C |
| insulation resistance | 1000 MOhm at 500 V DC |
| resistance | 4400 Ohm +/- 10 % |
| mounting position | any position |
| colour of cover | transparent |
| safety reliability data | B10d = 100000 |
| Razred električne izolacije | class F |
| maximum switching voltage | 250 V AC 30 V DC |
| dielectric strength | 1000 V AC between contacts with micro disconnection 5000 V AC between coil and contact with reinforced insulation |
| operating time | 20 ms |
| torque value | 0.8 N.m |
| contact resistance | 100 mOhm |
| reset time | 20 ms |
| load current | 10 A at 250 V AC |
| utilisation coefficient | 20 % |
| maximum switching capacity | 2500 VA |
| operating rate | <= 1800 cycles/hour under load <= 18000 cycles/hour no-load |
| test levels | level A group mounting |
| drop-out voltage threshold | >= 0.1 Uc DC |
| minimum switching capacity | 500 mW at 100 mA, 5 V DC |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -40-70 °C |
| IP stopnja zaščite | IP40 |
| Stopnja onesnaženosti | 2 |
| Temperatura okoliškega zraka za skladiščenje | -40-85 °C |
| relative humidity | 10-85 % |
| overvoltage category | III |
| Certifikati izdelkov | CE CSA UL RoHS EAC REACH China RoHS |
| Standardi | UL 508 IEC 61810-1 CSA C22.2 No 14 |
| Odporno proti udarcu | 20 gn in operation 100 gn not in operation |
| Odpornost proti vibracijam | 3 gn, amplitude = +/- 0.75 mm (f = 10-150 Hz)in operation 5 gn, amplitude = +/- 0.75 mm (f = 10-150 Hz)not in operation |
| protection category | RT I |
