NSYTBS1176 Schneider Electric
NSYTBS1176 Schneider Electric
Opis
ABS box IP66 IK07 RAL7035 Int.H105W65D55 Ext.H116W74D62 Opaque cover H10
Tehnične lastnosti
| Glavno | |
| Izdelek ali sestavni del | industrial box |
| product name | Thalassa TBS |
| Skupina izdelkov | Thalassa |
| Aplikacija naprave | multi-purpose |
| device composition | 1 body 1 cover 4 cover screw |
| body type | one piece moulded |
| Količina na set/komplet | set of 5 |
| type of front cover | low plain cover |
| depth | 62 mm |
| width | 74 mm |
| height | 116 mm |
| enclosure mounting | wall mounted |
| removable parts | cover by captive screws |
| lock type | captive screw flat outside sealed area |
| cover fixing | metal screws |
| internal width | 65 mm |
| internal height | 105 mm |
| internal depth | 55 mm |
| Komplementarno | |
| Teža izdelka | 0.108 kg |
| colour | grey (RAL 7035) |
| product certifications | DEMKO TÜV SEMKO |
| standards | IEC 62208 |
| Material | ABS (acrylonitrile butadiene-styrene) |
| ambient air temperature for operation | -25-60 °C |
| IP degree of protection | IP66 conforming to NEMA 4.4X |
| Razred električne izolacije | class II |
| IK degree of protection | IK07 conforming to IEC 62262 |
| ambient air temperature for storage | -15-40 °C |
| fire resistance | 650 °C conforming to IEC 60695-2-11 |
