KBB25ED2303TW Schneider Electric
KBB25ED2303TW Schneider Electric
Opis
STRAIGHT DISTRIBUTION LENGTHS 25A 3M
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Canalis |
| Izdelek ali sestavni del | busbar trunking |
| Skupina izdelkov | Canalis |
| Kratko ime naprave | KBB |
| Združljivost izdelkov | KBB |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Višina | 60 mm |
| Teža izdelka | 2.4 kg |
| control type | communicating |
| [Ui] Nazivna izolacijska trdnost | 690 V |
| mounting mode | by screws |
| [Uimp] rated impulse withstand voltage | 4 kV |
| colour | white (RAL 9003) |
| Širina | 3100 mm |
| Globina | 51 mm |
| [Ue] rated operational voltage | 230...400 V |
| standards | EN/IEC 61439-6 EN/IEC 60439-2 |
| [Ie] rated operational current | 25 A at 35 °C |
| quantity per set | set of 6 |
| [Icw] rated short-time withstand current | 0.44 kA |
| THDI | 0-15 % 25 A 15-33 % 20 A 33-100 % 16 A |
| linear resistance | 6.8 mΩ/m R20 20 °C phase conductor 8.3 mΩ/m R1 35 °C at Inc and 50 Hz phase conductor 0.02 mΩ/m X1 35 °C at Inc and 50 Hz phase conductor 8.33 mΩ/m Z1 35 °C at Inc and 50 Hz phase conductor 27.21 mΩ/m R0 20 °C symmetrical components method Ph/N 0.85 mΩ/m X0 20 °C symmetrical components method Ph/N 27.22 mΩ/m Z0 20 °C symmetrical components method Ph/N 13.61 mΩ/m Rb0 20 °C impedance method Ph/Ph 13.61 mΩ/m Rb0 20 °C impedance method Ph/N 0.8 mΩ/m protective conductor 17.28 mΩ/m R0 20 °C symmetrical components method Ph/PE 5.25 mΩ/m X0 20 °C symmetrical components method Ph/PE 18.06 mΩ/m Z0 20 °C symmetrical components method Ph/PE 10.26 mΩ/m Rb0 20 °C impedance method Ph/PE 16.59 mΩ/m Rb1 35 °C at Inc with impedance method Ph/Ph 16.59 mΩ/m Rb1 35 °C at Inc with impedance method Ph/N 11.77 mΩ/m Rb1 35 °C at Inc with impedance method Ph/PE 0.35 mΩ/m Xb 35 °C at Inc and 50 Hz with impedance method Ph/Ph 0.35 mΩ/m Xb 35 °C at Inc and 50 Hz with impedance method Ph/N 0.07 mΩ/m Xb 35 °C at Inc and 50 Hz with impedance method Ph/PE |
| maximum voltage drop | <0.72 V with power factor = 1 at 50 Hz with 1A for 100 m long <0.67 V with power factor = 0.9 at 50 Hz with 1A for 100 m long <0.61 V with power factor = 0.8 at 50 Hz with 1A for 100 m long <0.55 V with power factor = 0.7 at 50 Hz with 1A for 100 m long |
| [Ipk] rated peak withstand current | 4.4 kA |
| thermal stress limit | 195 kA².s |
| number of tap-off outlets | 3 |
| busbar trunking polarity | L + N + PE |
| length | 3 m |
| device application | power socket distribution lighting |
| number of circuits | 1 |
| busbar description | straight length |
| maximum radiated magnetic field | 2 pT |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | 0-35 °C (100 % of In) 35-40 °C (96 % of In) 40-45 °C (93 % of In) 45-50 °C (89 % of In) 50-55 °C (85 % of In) |
| IP stopnja zaščite | IP55 conforming to EN/IEC 60529 |
| IK stopnja zaščite | IK06 conforming to EN/IEC 62262 |
