KTC2500YA4 Schneider Electric
KTC2500YA4 Schneider Electric
Opis
KT 4X2500CO JUNCTION BLOC
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Canalis |
| Izdelek ali sestavni del | electrical and mechanical jointing |
| product name | KT |
| Skupina izdelkov | Canalis |
| Aplikacija naprave | jointing |
| Kratko ime naprave | KTC |
| Kategorija dodatkov/ločenih delov | connection accessory |
| [Ie] rated operational current | 2500 A with copper |
| Material | copper |
| length | 360 mm |
| busbar trunking polarity | 3L + N + PE |
| Združljivost serije/obsega | KT |
| Komplementarno | |
| Višina | 204 mm |
| mounting support | self-tapping screw |
| colour | white (RAL 9001) |
| Širina | 141 mm |
| [Ue] rated operational voltage | 1000 V |
| standards | IEC 61439-6 IEC 61439-1 |
| contacts material | copper |
| housing material | polyester film |
| earth circuit | standard earth |
| number of circuits | 1 |
| offer type | spare part |
| variant | standard version |
| Okolje | |
| IP stopnja zaščite | IP55 conforming to IEC 60529 |
| IK stopnja zaščite | IK08 conforming to IEC 62262 |
