KTC1000ZC32 Schneider Electric
KTC1000ZC32 Schneider Electric
Opis
KT 3X1000CO EDGEWISE ZED N2
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Canalis |
| Izdelek ali sestavni del | zed elbow |
| product name | KT |
| Skupina izdelkov | Canalis |
| Aplikacija naprave | change direction |
| Kratko ime naprave | KTC |
| [Ie] rated operational current | 1000 A at 35 °C |
| busbar description | standard |
| earth circuit | standard earth |
| variant | standard version |
| Provided equipment | trunking unit jointing unit |
| Material | copper |
| busbar trunking polarity | 3L + PE |
| direction change type | direction 2 : edgewise to horizontal direction 1 : edgewise to downward |
| operating angle | 90-90 ° |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Višina | direction 2 : 90-549 mm |
| [Ui] Nazivna izolacijska trdnost | 1000 V |
| colour | white (RAL 9001) |
| Širina | 140 mm |
| [Ue] rated operational voltage | 1000 V |
| standards | IEC 61439-1 IEC 61439-6 |
| contacts material | copper |
| [Icw] rated short-time withstand current | 50 kA |
| dimension type | made to measure |
| THDI | 0-15 % 1000 A |
| linear resistance | L - L: Xb 35 °C= 0.04 mΩ/m at Inc and 50 Hz with impedance method L - PE: Xb 35 °C= 0.426 mΩ/m at Inc and 50 Hz with impedance method L: R1 35 °C= 0.049 mΩ/m at Inc and 50 Hz L: X1 35 °C= 0.022 mΩ/m at Inc and 50 Hz L: Z1 35 °C= 0.054 mΩ/m at Inc and 50 Hz L - PE: R0 20 °C= 0.688 mΩ/m symmetrical components method L - PE: X0 20 °C= 0.666 mΩ/m symmetrical components method L - PE: Z0 20 °C= 0.958 mΩ/m symmetrical components method L - L: Rb0 20 °C= 0.078 mΩ/m impedance method L - PE: Rb0 20 °C= 0.439 mΩ/m impedance method L - L: Rb1 35 °C= 0.094 mΩ/m at Inc with impedance method L - PE: Rb1 35 °C= 0.527 mΩ/m at Inc with impedance method PE: 20 °C= 0.203 mΩ/m L: R20 20 °C= 0.041 mΩ/m |
| housing material | polyester film |
| neutral position | right |
| linear load | 19 kg/m |
| radiated magnetic field | 0.4 µT |
| maximum voltage drop | <0.0043 V with power factor = 1 at 50 Hz with 1A for 100 m long <0.0047 V with power factor = 0.9 at 50 Hz with 1A for 100 m long <0.0046 V with power factor = 0.8 at 50 Hz with 1A for 100 m long <0.0044 V with power factor = 0.7 at 50 Hz with 1A for 100 m long |
| [Ipk] rated peak withstand current | 110 kA |
| thermal stress limit | 2500 A².s |
| length | direction 3 : 275-275 mm direction 1 : 275-275 mm |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | 0-35 °C (100 % of In) 35-40 °C (95 % of In) 40-45 °C (90 % of In) 45-50 °C (84 % of In) 50-55 °C (79 % of In) |
| IP stopnja zaščite | IP55 conforming to IEC 60529 |
| IK stopnja zaščite | IK08 conforming to IEC 62262 |
