Opis
KT 4X1000AL FLAT EDGEWISE N4
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Canalis |
| Izdelek ali sestavni del | multiple elbow |
| product name | KT |
| Skupina izdelkov | Canalis |
| Aplikacija naprave | change direction |
| Kratko ime naprave | KTA |
| [Ie] rated operational current | 1000 A at 35 °C |
| busbar description | standard |
| earth circuit | standard earth |
| variant | standard version |
| Provided equipment | jointing unit trunking unit |
| Material | aluminium |
| busbar trunking polarity | 3L + N + PE |
| direction change type | direction 2 : edgewise to upward direction 1 : flat to left |
| operating angle | 90-90 ° |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Višina | direction 2 : 210-589 mm |
| [Ui] Nazivna izolacijska trdnost | 1000 V |
| colour | white (RAL 9001) |
| Širina | 140 mm |
| [Ue] rated operational voltage | 1000 V |
| standards | IEC 61439-1 IEC 61439-6 |
| contacts material | copper |
| [Icw] rated short-time withstand current | 50 kA |
| dimension type | made to measure |
| THDI | 0-15 % 1000 A 15-33 % 1250 A 33-100 % 1600 A |
| linear resistance | L: R1 35 °C= 0.069 mΩ/m at Inc and 50 Hz L: X1 35 °C= 0.016 mΩ/m at Inc and 50 Hz L: Z1 35 °C= 0.071 mΩ/m at Inc and 50 Hz L - PE: R0 20 °C= 0.676 mΩ/m symmetrical components method L - PE: X0 20 °C= 0.586 mΩ/m symmetrical components method L - PE: Z0 20 °C= 0.895 mΩ/m symmetrical components method L - L: Rb0 20 °C= 0.115 mΩ/m impedance method L - PE: Rb0 20 °C= 0.44 mΩ/m impedance method L - L: Rb1 35 °C= 0.14 mΩ/m at Inc with impedance method L - PE: Rb1 35 °C= 0.535 mΩ/m at Inc with impedance method L - L: Xb 35 °C= 0.029 mΩ/m at Inc and 50 Hz with impedance method L - PE: Xb 35 °C= 0.329 mΩ/m at Inc and 50 Hz with impedance method L-N: R0 20 °C= 0.248 mΩ/m symmetrical components method L-N: X0 20 °C= 0.103 mΩ/m symmetrical components method L-N: Z0 20 °C= 0.269 mΩ/m symmetrical components method L-N: Rb0 20 °C= 0.115 mΩ/m impedance method L-N: Rb1 35 °C= 0.14 mΩ/m at Inc with impedance method L-N: Xb 35 °C= 0.047 mΩ/m at Inc and 50 Hz with impedance method L: R20 20 °C= 0.057 mΩ/m PE: 20 °C= 0.178 mΩ/m |
| housing material | polyester film |
| neutral position | left |
| linear load | 16 kg/m |
| radiated magnetic field | 0.5 µT |
| maximum voltage drop | <0.006 V with power factor = 1 at 50 Hz with 1A for 100 m long <0.006 V with power factor = 0.9 at 50 Hz with 1A for 100 m long <0.0056 V with power factor = 0.8 at 50 Hz with 1A for 100 m long <0.0052 V with power factor = 0.7 at 50 Hz with 1A for 100 m long |
| [Ipk] rated peak withstand current | 110 kA |
| thermal stress limit | 2500 A².s |
| length | direction 1 : 300-300 mm direction 3 : 290-290 mm |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | 0-35 °C (100 % of In) 35-40 °C (97 % of In) 40-45 °C (93 % of In) 45-50 °C (90 % of In) 50-55 °C (86 % of In) |
| IP stopnja zaščite | IP55 conforming to IEC 60529 |
| IK stopnja zaščite | IK08 conforming to IEC 62262 |
