NG125 - circuit breaker - NG125L - 3P - 40A - D curve
Tehnične lastnosti
| Glavno | |
| [In] rated current | 40 A at 40 °C |
| Serija izdelka | NG125 |
| curve code | D |
| number of protected poles | 3 |
| network type | DC AC |
| breaking capacity code | L |
| Izdelek ali sestavni del | miniature circuit-breaker |
| product name | Acti 9 NG125 |
| utilisation category | category A conforming to IEC 60947-2 |
| Skupina izdelkov | Acti 9 |
| breaking capacity | 100 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-2 40 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-2 50 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-2 15 kA Icu at 500 V AC 50/60 Hz conforming to EN/IEC 60947-2 36 kA Icu at <= 375 V DC conforming to EN/IEC 60947-2 |
| suitability for isolation | yes conforming to IEC 60947-2 |
| Opis polov | 3P |
| Aplikacija naprave | distribution |
| Kratko ime naprave | NG125L |
| trip unit technology | thermal-magnetic |
| Komplementarno | |
| network frequency | 50/60 Hz |
| [Ics] rated service breaking capacity | 75 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz 37.5 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz 30 kA 75 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz 11.25 kA 75 % conforming to EN/IEC 60947-2 - 500 V AC 50/60 Hz 50 kA 100 % conforming to EN/IEC 60947-2 - 375 V DC |
| Višina | 103 mm |
| contact position indicator | yes |
| earth-leakage protection | separate block |
| mounting support | 35 mm symmetrical DIN rail |
| 9 mm pitches | 9 |
| magnetic tripping limit | 12 x In +/- 20 % |
| comb busbar and distribution block compatibility | YES |
| Teža izdelka | 0.72 kg |
| Povezave - terminali | tunnel type terminals1.5-50 mm² rigid tunnel type terminals1-35 mm² flexible |
| wire stripping length | 20 mm |
| control type | manual tripping test toggle |
| [Ui] Nazivna izolacijska trdnost | 690 V AC 50/60 Hz conforming to EN/IEC 60947-2 |
| mounting mode | clip-on |
| electrical durability | 10000 cycles |
| mechanical durability | 20000 cycles |
| Kompatibilnostna koda | NG125 |
| local signalling | trip indicator ON/OFF indication |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
| Širina | 81 mm |
| Globina | 81 mm |
| tightening torque | 3.5-3.5 N.m |
| [Ue] rated operational voltage | <= 375 V DC 380...415 V AC 50/60 Hz 500 V AC 50/60 Hz 220...240 V AC 50/60 Hz 440 V AC 50/60 Hz |
| locking options description | integrated padlocking |
| provision for padlocking | padlockable |
| market segment | small commercial small buildings |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -30-70 °C |
| tropicalisation | 2 conforming to IEC 60068-1 |
| IP stopnja zaščite | IP20 conforming to IEC 60529 |
| Stopnja onesnaženosti | 3 conforming to IEC 60947-2 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| relative humidity | 95-95 % at 55-55 °C |
| overvoltage category | IV |
| Nadmorska višina delovanja | 2000 m |
| IK stopnja zaščite | IK05 conforming to EN/IEC 62262 |
| Standardi | EN/IEC 60947-2 |
