Opis
basic switch disconnector, Compact NS1600 NA, withdrawable manually operated, 1600 A, 690 VAC 50/60 Hz, 4 poles
Tehnične lastnosti
| Glavno | |
| Serija izdelka | NS630b...1600 |
| network type | AC |
| breaking capacity code | NA |
| Izdelek ali sestavni del | switch disconnector |
| product name | Compact NS |
| Skupina izdelkov | Compact |
| suitability for isolation | yes conforming to IEC 60947-3 |
| Opis polov | 4P |
| Aplikacija naprave | distribution |
| Kratko ime naprave | Compact NS1600 NA |
| offer type | C4 |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Višina | 327 mm |
| contact position indicator | yes |
| mounting support | chassis |
| Teža izdelka | 18 kg |
| control type | toggle |
| [Ui] Nazivna izolacijska trdnost | 800 V AC 50/60 Hz conforming to IEC 60947-3 |
| mounting mode | drawout |
| electrical durability | 1000 cycles 440 V AC 50/60 Hz conforming to IEC 60947-3 |
| mechanical durability | 6000 cycles conforming to IEC 60947-3 |
| Kompatibilnostna koda | NS1600 |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-3 |
| Širina | 280 mm |
| Globina | 147 mm |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Ith] conventional free air thermal current | 1600 A at 60 °C |
| [Icm] rated short-circuit making capacity | 52 kA 690 V AC at 50/60 Hz |
| [Ie] rated operational current | AC-23A: 1600 A AC 50/60 Hz 220/240 V AC-23A: 1600 A AC 50/60 Hz 380/415 V AC-23A: 1600 A AC 50/60 Hz 440/480 V AC-23A: 1600 A AC 50/60 Hz 500/525 V AC-23A: 1600 A AC 50/60 Hz 660/690 V |
| [Icw] rated short-time withstand current | 25 kA during 0.5 s conforming to IEC 60947-3 4 kA during 20 s conforming to IEC 60947-3 |
| connection pitch | 115 mm |
| visible break | no |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| Stopnja onesnaženosti | 3 conforming to IEC 60947-3 |
| Temperatura okoliškega zraka za skladiščenje | -50-85 °C |
| Certifikati izdelkov | ASTA ASEFA |
| Standardi | IEC 60947-3 |
