LV516428 Schneider
LV516428 Schneider
Opis
switch disconnector EasyPact Vigi CVS160NA, 4 poles, 160 A, AC22A, AC23A
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Easypact CVS100...250 |
| network type | AC |
| breaking capacity code | NA |
| Izdelek ali sestavni del | earth leakage switch disconnector |
| product name | EasyPact CVS |
| utilisation category | AC-22A AC-23A |
| Skupina izdelkov | EasyPact |
| suitability for isolation | yes conforming to EN 60947-3 yes conforming to IEC 60947-3 |
| Opis polov | 4P |
| Aplikacija naprave | distribution |
| Kratko ime naprave | Vigi CVS160NA |
| [Ie] rated operational current | AC-22A: 160 A AC 50/60 Hz 220/240 V AC-22A: 160 A AC 50/60 Hz 380/415 V AC-22A: 160 A AC 50/60 Hz 440 V AC-23A: 160 A AC 50/60 Hz 220/240 V AC-23A: 160 A AC 50/60 Hz 380/415 V AC-23A: 160 A AC 50/60 Hz 440 V |
| earth-leakage protection | with |
| earth-leakage add-on module name | MH |
| [Ith] conventional free air thermal current | 160 A at 50 °C |
| [Icm] rated short-circuit making capacity | 75 kA with upstream protection circuit breaker 3.6 kA switch-disconnector alone |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Višina | 236 mm |
| contact position indicator | yes |
| mounting support | backplate |
| control type | toggle |
| mounting mode | fixed |
| electrical durability | AC-22A: 8000 cycles 415 V AC 50/60 Hz In conforming to IEC 60947-3 AC-23A: 8000 cycles 415 V AC 50/60 Hz In conforming to IEC 60947-3 |
| mechanical durability | 25000 cycles conforming to IEC 60947-3 |
| Kompatibilnostna koda | CVS160 |
| Širina | 140 mm |
| Globina | 86 mm |
| upside connection | front |
| downside connection | front |
| [Icw] rated short-time withstand current | 0.96 kA during 20 s conforming to IEC 60947-3 2.5 kA during 1 s conforming to IEC 60947-3 2.5 kA during 3 s conforming to IEC 60947-3 |
| connection pitch | 35 mm |
| residual earth-leakage sensitity adjustment type | adjustable 5 settings |
| [Δt] residual earth-leakage time delay adjustment | 150-150 ms 0-0 ms 310-310 ms 60-60 ms |
| [IΔn] residual earth-leakage sensitive adjustment | 0.3-0.3 A 3-3 A 0.03-0.03 A 10-10 A 1-1 A |
| residual earth-leakage time delay adjustment type | adjustable 4 settings |
| visible break | no |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| Stopnja onesnaženosti | 3 conforming to IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -50-85 °C |
| Certifikati izdelkov | IEC GOST |
| Standardi | IEC 60947-3 EN 60947-3 |
| electrical shock protection class | class II |
