03271 Schneider
03271 Schneider
Opis
FRONT PLATE INS630 HORIZONTAL W600 9M
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Prisma G |
| Izdelek ali sestavni del | front plate |
| Skupina izdelkov | Prisma |
| Opis polov | 1 x 3P: mounting plate support: INS320...400 horizontal installation 1 x 4P: mounting plate support: INS320...400 horizontal installation 1 x 3P: mounting plate support: INS500...630 horizontal installation 1 x 4P: mounting plate support: INS500...630 horizontal installation 1 x 3P: mounting plate support: INV320...400 horizontal installation 1 x 4P: mounting plate support: INV320...400 horizontal installation 1 x 3P: mounting plate support: INV500...630 horizontal installation 1 x 4P: mounting plate support: INV500...630 horizontal installation |
| Kategorija dodatkov/ločenih delov | installation accessory |
| operating position | horizontal |
| Združljivost serije/obsega | Prisma G |
| installed device | Compact: fixed INS320...400 - control: direct front rotary handle - horizontal installation Compact: fixed INS500...630 - control: direct front rotary handle - horizontal installation Compact: fixed INV320...400 - control: direct front rotary handle - horizontal installation Compact: fixed INV500...630 - control: direct front rotary handle - horizontal installation |
| type of front plate | cut-out |
| Komplementarno | |
| Višina | 300 mm |
| Teža izdelka | 1.08 kg |
| colour | white (RAL 9001) |
| Širina | 500 mm |
| product certifications | ASEFA |
| standards | IEC 61439-1 IEC 61439-2 |
| Material | steel |
| surface finish | smooth matt |
| quantity per set | set of 1 |
| enclosure/cubicle description | floor-standing enclosure + duct - width 600 + 300 mm wall-mounted enclosure + duct - width 600 + 300 mm |
| connection position | direct connection |
| number of vertical modules [50 mm] | 6 |
| protective treatment | electrophoresis treatment and hot-polymerised polyester epoxy powder |
| enclosure/cubicle width | 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INS500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV320...400 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 9 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 3P 1 direct with long terminal shield 6 600 + 300 mm Prisma G floor-standing enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 600 + 300 mm Prisma G wall-mounted enclosure + duct Compact INV500...630 fixed direct front rotary handle horizontal 4P 1 direct with long terminal shield 6 |
| Okolje | |
| IK stopnja zaščite | IK07 conforming to EN/IEC 62262 |
