NSYPLS2727AG Schneider Electric
NSYPLS2727AG Schneider Electric
Opis
PLS box, polyester rear, transparent PC cover IP65 27x27x23cm
Tehnične lastnosti
| Glavno | |
| Izdelek ali sestavni del | insulating modular box |
| product name | Thalassa PLS |
| Skupina izdelkov | Thalassa |
| Aplikacija naprave | multi-purpose |
| Kratko ime naprave | PLS |
| device composition | 1 cover: on enclosure 1 rear part: on enclosure locking screws |
| enclosure nominal height | 270 mm |
| enclosure nominal depth | 230 mm |
| enclosure nominal width | 270 mm |
| body type | one piece moulded |
| type of front cover | high transparent cover |
| enclosure mounting | wall mounted |
| lock type | slot screw |
| Komplementarno | |
| colour | body: grey (RAL 7035) |
| product certifications | UL |
| removable parts | cover locking screw |
| standards | NEMA 4X IEC 62208 NEMA classification 13 |
| Material | cover: polycarbonate rear: polyester reinforced with fibreglass |
| Okolje | |
| IP stopnja zaščite | IP65 conforming to IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -30-70 °C |
| IK stopnja zaščite | IK09 conforming to IEC 62262 |
| fire resistance | 960 °C conforming to IEC 62208 |
| electrical insulation class | class II |
