XKBA1133CA Schneider

XKBA light hoisting applications joystick controller

Glavno
Serija izdelka	Harmony XK
Izdelek ali sestavni del	complete joystick controller
product specific application	light hoisting applications
Komplementarno
Povezave - terminali	captive screw clamp terminals, <= 2 x 1.5 mm² with cable end captive screw clamp terminals, <= 1 x 2.5 mm² without cable end captive screw clamp terminals, >= 1 x 0.5 mm²
[Ui] Nazivna izolacijska trdnost	500 V (pollution degree 3) conforming to IEC 60947-1
mechanical durability	1000000 cycles
Kompatibilnostna koda	XKB
standards	CSA C22.2 No 14 UL 508 EN/IEC 60947-5-1
short-circuit protection	10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1
[Ith] conventional free air thermal current	10 A conforming to EN/IEC 60947-5-1 10 A conforming to CSA C22.2 No 14 10 A conforming to UL 508
bezel material	metal
ambient air temperature for operation	-20-70 °C
overvoltage category	class I conforming to IEC 61140
operator position information	all positions
notch per direction	1-3 notches at 0-12°-20°-28° for each direction
ambient air temperature for storage	-40-70 °C
operator profile	standard handle
sale per indivisible quantity	1
shock resistance	20 gn (duration = 11 ms) conforming to IEC 60068-2-27
protective treatment	TC
vibration resistance	6 gn (f= 1-70 Hz) conforming to IEC 60068-2-6
device short name	XKB
fixing collar material	metal
