XB6AW1B5B Schneider Electric
XB6AW1B5B Schneider Electric
Opis
white flush complete illum pushbutton Ø16 spring return 1NO+1NC 12...24V
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony XB6 |
| Izdelek ali sestavni del | complete illuminated push-button |
| Kratko ime naprave | XB6 |
| [Us] Nazivna napajalna npetost | 12...24 V AC/DC |
| Izvor svetlobe | LED |
| mounting diameter | 16 mm |
| Oblika glave signalne enote | round |
| Prodaja na nedeljivo količino | 1 |
| bezel material | plastic |
| Grlo žarnice | integral LED |
| type of operator | spring return |
| operator profile | white flush, unmarked |
| contacts type and composition | 1 NO + 1 NC |
| contact operation | slow-break |
| connections - terminals | Faston connectors, connection size: 2.8 x 0.5 mm |
| Komplementarno | |
| Teža izdelka | 0.025 kg |
| [Ui] Nazivna izolacijska trdnost | 250 V (pollution degree 3) conforming to EN/IEC 60947-1 |
| electrical durability | 1000000 cycles, AC-15 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C 1000000 cycles, DC-13 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C |
| Kompatibilnostna koda | XB6 |
| terminals description ISO n°1 | (13-14)NO (21-22)NC |
| Poraba toka | 15 mA |
| Prenapetostna vzdržljivost | 1 kV direct contact conforming to IEC 61000-4-5 2 kV in free air conforming to IEC 61000-4-5 |
| Tip signalizacije | steady |
| Omejitve napajalne napetosti | 6-30 V AC/DC |
| contacts material | silver alloy (Ag/Ni) |
| short-circuit protection | 6 A cartridge fuse type gG |
| positive opening | with conforming to EN/IEC 60947-5-1 appendix K |
| CAD overall height | 18 mm |
| operating position | any position |
| CAD overall width | 18 mm |
| CAD overall depth | 57 mm |
| [Ie] rated operational current | 3 A at 120 V, AC-15, B300 conforming to EN/IEC 60947-5-1 1.5 A at 240 V, AC-15, B300 conforming to EN/IEC 60947-5-1 0.1 A at 250 V, DC-13, R300 conforming to EN/IEC 60947-5-1 0.22 A at 125 V, DC-13, R300 conforming to EN/IEC 60947-5-1 |
| electrical reliability | λ = 10exp(-8) at 5 V and 1 mA with confidence level of 90 % conforming to IEC 60947-5-4 |
| operating force | 3.5 N NO changing electrical state 4.5 N NC changing electrical state |
| operating travel | 1 mm (NO changing electrical state) 2 mm (NC changing electrical state) 3.5 mm (total travel) |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| IP stopnja zaščite | IP65 conforming to IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | GOST UL CSA CCC |
| Odpornost na elektromagnetna polja | 10 V/m conforming to IEC 61000-4-3 |
| Standardi | CSA C22.2 No 14 EN/IEC 60947-5-5 JIS C 4520 EN/IEC 60947-1 JIS C 852 EN/IEC 60947-5-1 |
| Odporno proti udarcu | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | +/- 3 mm (f= 2-500 Hz) conforming to IEC 60068-2-6 5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| NEMA degree of protection | NEMA 13 conforming to UL 50 NEMA 4 conforming to UL 50 NEMA 4X conforming to UL 50 NEMA 13 conforming to CSA C22.2 No 94 NEMA 4 conforming to CSA C22.2 No 94 NEMA 4X conforming to CSA C22.2 No 94 |
| Odpornost na elektrostatično razelektritev | 6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2 |
| electrical shock protection class | class II conforming to IEC 61140 |
| Zaščitna obdelava | TC |
| Odpornost proti hitrim prehodnim pojavom | 2 kV conforming to IEC 61000-4-4 |
| Elektromagnetne emisije | class B conforming to IEC 55011 |
