K63D004HP Schneider Electric
K63D004HP Schneider Electric
Opis
cam switch - 4-pole - 90° - 63 A - screw mounting
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony K |
| Izdelek ali sestavni del | complete cam switch |
| Opis polov | 4P |
| type of operator | black handle |
| IP degree of protection | IP40 conforming to IEC 529 IP40 conforming to NF C 20-010 |
| fixing mode | 4 holes |
| component name | K63 |
| [Ith] conventional free air thermal current | 63 A |
| product mounting | front mounting |
| cam switch function | switch |
| switching positions | right: 0° - 90° |
| off position | with Off position |
| cam switch head type | with front plate 64 x 64 mm |
| presentation of legend | with metallic legend, OFF-ON black marking |
| rotary handle padlocking | without |
| return | without |
| Komplementarno | |
| Teža izdelka | 0.39 kg |
| [Ui] Nazivna izolacijska trdnost | 690 V (pollution degree 3) conforming to EN 60947-1 690 V (pollution degree 3) conforming to IEC 60947-1 |
| mechanical durability | 300000 cycles |
| Kompatibilnostna koda | K63D |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to EN 947-1 6 kV conforming to IEC 947-1 |
| tightening torque | 2.5 N.m |
| short-circuit protection | 80 A cartridge fuse, type gG |
| positive opening | with |
| CAD overall height | 64 mm |
| contact operation | slow-break |
| CAD overall width | 64 mm |
| CAD overall depth | 111 mm |
| electrical connection | captive screw clamp terminals flexible, clamping capacity: 2 x 10 mm² captive screw clamp terminals solid, clamping capacity: 2 x 16 mm² |
| switching capacity in mA | 20000 mA DC at 140 V 3 contact(s) for inductive load (T = 50 ms) 63000 mA DC at 140 V 3 contact(s) for resistive load (T = 1 ms) 63000 mA DC at 24 V 1 contact(s) for inductive load (T = 50 ms) 63000 mA DC at 24 V 1 contact(s) for resistive load (T = 1 ms) 63000 mA DC at 48 V 1 contact(s) for resistive load (T = 1 ms) 63000 mA DC at 48 V 2 contact(s) for inductive load (T = 50 ms) 63000 mA DC at 48 V 2 contact(s) for resistive load (T = 1 ms) 63000 mA DC at 70 V 3 contact(s) for inductive load (T = 50 ms) 63000 mA DC at 70 V 3 contact(s) for resistive load (T = 1 ms) 63000 mA DC at 95 V 2 contact(s) for resistive load (T = 1 ms) 20000 mA DC at 48 V 1 contact(s) for inductive load (T = 50 ms) 20000 mA DC at 95 V 2 contact(s) for inductive load (T = 50 ms) 30000 mA DC at 120 V 2 contact(s) for resistive load (T = 1 ms) 30000 mA DC at 180 V 3 contact(s) for resistive load (T = 1 ms) 30000 mA DC at 60 V 1 contact(s) for resistive load (T = 1 ms) 55000 mA DC at 30 V 1 contact(s) for inductive load (T = 50 ms) 55000 mA DC at 60 V 2 contact(s) for inductive load (T = 50 ms) 55000 mA DC at 90 V 3 contact(s) for inductive load (T = 50 ms) |
| short-circuit current | 10000 A |
| switching angle | 90 ° |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-55 °C |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | cULus 120 V 3 hp 1 phase cULus 480 V 25 hp 3 phases cULus 240 V 7.5 hp 1 phase cULus 240 V 10 hp 3 phases |
| Standardi | EN/IEC 60947-3 |
| electrical shock protection class | class II conforming to IEC 60536 class II conforming to NF C 20-030 |
| Zaščitna obdelava | TC |
