K2B001U Schneider
K2B001U Schneider
Opis
body for changeover switch - 1 pole - 45° - 20 A - for Ø 22 mm
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony K |
| Izdelek ali sestavni del | cam switch body |
| Opis polov | 1P |
| bezel material | plastic |
| fixing mode | Ø 22 mm hole |
| Lokacija montaže | front |
| component name | K2 |
| [Ith] conventional free air thermal current | 20 A |
| sub-assembly composition | contact blocks + fixing plate |
| cam switch function | reversing switch |
| switching positions | right: 0° - 45° left: 0° - 315° |
| off position | with Off position |
| Komplementarno | |
| Teža izdelka | 0.085 kg |
| [Ui] Nazivna izolacijska trdnost | 690 V (pollution degree 3) conforming to IEC 60947-1 |
| electrical durability | 200000 cycles AC-23 200000 cycles AC-3 600000 cycles AC-15 600000 cycles AC-21 |
| mechanical durability | 1000000 cycles |
| Kompatibilnostna koda | K2B |
| [Uimp] rated impulse withstand voltage | 4 kV in isolating function 6 kV conforming to IEC 947-1 |
| short-circuit protection | 20 A cartridge fuse, type gG |
| positive opening | with |
| contact operation | slow-break |
| electrical connection | captive screw clamp terminals flexible, clamping capacity: 2 x 1.5 mm² captive screw clamp terminals solid, clamping capacity: 1 x 2.5 mm² |
| maximum operating rate | 2.5 cyc/mn AC-21 2.5 cyc/mn AC-23 2.5 cyc/mn AC-3 8.333 cyc/mn AC-15 |
| [Ithe] conventional enclosed thermal current | 16 A |
| short-circuit current | 10000 A |
| rated operational power in W | 1300 W AC-3, 230 V 1 phase conforming to IEC 947-3 5500 W AC-23A, 400 V 3 phases conforming to IEC 947-3 5500 W AC-23A, 500 V 3 phases conforming to IEC 947-3 5500 W AC-23A, 690 V 3 phases conforming to IEC 947-3 8000 W AC-21, 230 V 3 phases conforming to IEC 947-3 14000 W AC-21, 400 V 3 phases conforming to IEC 947-3 17000 W AC-21, 550...600 V 3 phases conforming to IEC 947-3 2200 W AC-3, 230 V 3 phases conforming to IEC 947-3 2200 W AC-3, 400 V 1 phase conforming to IEC 947-3 4000 W AC-23A, 230 V 3 phases conforming to IEC 947-3 4000 W AC-3, 400 V 3 phases conforming to IEC 947-3 4000 W AC-3, 500 V 3 phases conforming to IEC 947-3 4000 W AC-3, 690 V 3 phases conforming to IEC 947-3 |
| switching angle | 45 ° |
| [Ie] rated operational current AC | 8 A at 400 V AC-3 3 phases conforming to IEC 947-3 3 A at 400 V AC-15 conforming to IEC 947-5-1 4 A at 230 V AC-15 conforming to IEC 947-5-1 10.8 A at 400 V AC-23A 3 phases conforming to IEC 947-3 14.6 A at 230 V AC-23A 3 phases conforming to IEC 947-3 4.7 A at 690 V AC-3 3 phases conforming to IEC 947-3 6.4 A at 690 V AC-23A 3 phases conforming to IEC 947-3 6.5 A at 500 V AC-3 3 phases conforming to IEC 947-3 8.3 A at 230 V AC-3 3 phases conforming to IEC 947-3 8.9 A at 500 V AC-23A 3 phases conforming to IEC 947-3 2 A at 500 V AC-15 conforming to IEC 947-5-1 |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-55 °C |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| overvoltage category | class II conforming to IEC 536 class II conforming to NF C 20-030 |
| Certifikati izdelkov | CSA 240 V 1 hp 1 phase CSA 240 V 3 hp 3 phases 2 -pole(s) UL 240 V 1 hp 3 phases UL 240 V 0.33 hp 1 phase 2 -pole(s) |
| Standardi | EN/IEC 60947-3 for power circuit EN/IEC 60947-5-1 for control circuit CENELEC EN 50013 |
| Odporno proti udarcu | 30 gn conforming to IEC 68-2-27 |
| Odpornost proti vibracijam | 5 gn conforming to IEC 68-2-6 (f = 10-150 Hz) |
| Zaščitna obdelava | TC |
