K1D004HCH Schneider
K1D004HCH Schneider
Opis
cam switch - 4-pole - 90° - 12 A - for Ø 22 mm
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony K |
| Izdelek ali sestavni del | complete cam switch |
| Opis polov | 4P |
| type of operator | black handle, length = 35 mm |
| IP degree of protection | IP65 conforming to IEC 529 IP65 conforming to NF C 20-010 |
| fixing mode | Ø 22 mm hole |
| Lokacija montaže | front |
| component name | K1 |
| [Ith] conventional free air thermal current | 12 A |
| cam switch function | switch |
| switching positions | right: 0° - 90° |
| off position | with Off position |
| cam switch head type | with front plate 45 x 45 mm |
| presentation of legend | with metallic legend, 0 - 1 black marking |
| rotary handle padlocking | without |
| return | without |
| Komplementarno | |
| Teža izdelka | 0.16 kg |
| [Ui] Nazivna izolacijska trdnost | 690 V (pollution degree 3) conforming to IEC 60947-1 |
| electrical durability | 1000000 cycles AC-15 1000000 cycles AC-21 500000 cycles AC-23 500000 cycles AC-3 |
| mechanical durability | 1000000 cycles |
| Kompatibilnostna koda | K1D |
| [Uimp] rated impulse withstand voltage | 4 kV in isolating function 6 kV conforming to IEC 60947-1 |
| short-circuit protection | 16 A cartridge fuse, type gG |
| positive opening | with |
| CAD overall height | 50 mm |
| contact operation | slow-break |
| CAD overall width | 45 mm |
| CAD overall depth | 59 mm |
| electrical connection | captive screw clamp terminals flexible, clamping capacity: 2 x 1.5 mm² captive screw clamp terminals solid, clamping capacity: 1 x 2.5 mm² |
| maximum operating rate | 2.5 cyc/mn AC-21 2.5 cyc/mn AC-23 2.5 cyc/mn AC-3 8.333 cyc/mn AC-15 |
| [Ithe] conventional enclosed thermal current | 10 A |
| short-circuit current | 10000 A |
| rated operational power in W | 10500 W AC-21, 500...660 V 3 phases conforming to IEC 60947-3 2200 W AC-23A, 690 V 3 phases conforming to IEC 60947-3 4800 W AC-21, 230 V 3 phases conforming to IEC 60947-3 600 W AC-3, 230 V 1 phase conforming to IEC 60947-3 8300 W AC-21, 400 V 3 phases conforming to IEC 60947-3 1100 W AC-3, 230 V 3 phases conforming to IEC 60947-3 1500 W AC-23A, 230 V 3 phases conforming to IEC 60947-3 1500 W AC-3, 400 V 1 phase conforming to IEC 60947-3 1500 W AC-3, 400 V 3 phases conforming to IEC 60947-3 1500 W AC-3, 500 V 3 phases conforming to IEC 60947-3 1500 W AC-3, 690 V 3 phases conforming to IEC 60947-3 2200 W AC-23A, 400 V 3 phases conforming to IEC 60947-3 2200 W AC-23A, 500 V 3 phases conforming to IEC 60947-3 |
| switching angle | 90 ° |
| [Ie] rated operational current AC | 1.8 A at 690 V AC-3 3 phases conforming to IEC 60947-3 2 A at 400 V AC-15 conforming to IEC 60947-5-1 3 A at 230 V AC-15 conforming to IEC 60947-5-1 2.8 A at 500 V AC-3 3 phases conforming to IEC 60947-3 2.8 A at 690 V AC-23A 3 phases conforming to IEC 60947-3 3.3 A at 400 V AC-3 3 phases conforming to IEC 60947-3 3.8 A at 500 V AC-23A 3 phases conforming to IEC 60947-3 4.6 A at 230 V AC-3 3 phases conforming to IEC 60947-3 4.8 A at 400 V AC-23A 3 phases conforming to IEC 60947-3 5.6 A at 230 V AC-23A 3 phases conforming to IEC 60947-3 1 A at 500 V AC-15 conforming to IEC 60947-5-1 |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-55 °C |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| overvoltage category | class II conforming to IEC 536 class II conforming to NF C 20-030 |
| Certifikati izdelkov | CSA 240 V 3 hp 3 phases 2 -pole(s) UL 240 V 0.33 hp 1 phase 2 -pole(s) CSA 240 V 1 hp 1 phase UL 240 V 1 hp 3 phases |
| Standardi | EN 60947-3 for power circuit EN 60947-5-1 for control circuit IEC 60947-3 for power circuit IEC 60947-5-1 for control circuit CENELEC EN 50013 |
| Odporno proti udarcu | 30 gn conforming to IEC 68-2-27 |
| Odpornost proti vibracijam | 5 gn conforming to IEC 68-2-6 (f = 10-150 Hz) |
| Zaščitna obdelava | TC |
