9001KR9P35RH25 Schneider Electric
9001KR9P35RH25 Schneider Electric
Opis
PUSH BUTTON 600VAC 10A 30MM T-K
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony 9001K |
| Izdelek ali sestavni del | illuminated mushroom head push-button |
| Kratko ime naprave | 9001K |
| type of operator | push-pull |
| operator profile | red mushroom Ø 41 mm, unmarked |
| light block supply | direct |
| Komplementarno | |
| Teža izdelka | 0.168 kg |
| Povezave - terminali | screw clamp terminals, 1 x 0.22...2 x 1.5 mm² conforming to IEC 60947-1 |
| [Ui] Nazivna izolacijska trdnost | 250 V (pollution degree 3) conforming to IEC 60947-1 |
| mechanical durability | 5000000 cycles |
| Kompatibilnostna koda | 9001K |
| tightening torque | 0.8-0.8 N.m conforming to IEC 60947-1 |
| [Us] rated supply voltage | 24...28 V AC/DC |
| terminals description ISO n°1 | (11-12)NC_OL (21-22)NC |
| device presentation | complete product |
| contacts material | silver alloy contacts |
| short-circuit protection | 10 A cartridge fuse conforming to IEC 60947-5-1 |
| light source | incandescent |
| positive opening | with conforming to IEC 60947-5-2 |
| mounting diameter | 30 mm |
| [Ith] conventional free air thermal current | 10 A |
| rated breaking capacity | 1.2 kA at 600 V AC-15, 720 VA 1.5 kA at 480 V AC-15, 720 VA 3 kA at 240 V AC-15, 720 VA 6 kA at 120 V AC-15, 720 VA 0.1 kA at 600 V DC-13 0.27 kA at 250 V DC-13 0.55 kA at 125 V DC-13 |
| shape of signaling unit head | round |
| CAD overall height | 42 mm |
| [Icm] rated short-circuit making capacity | 12 kA at 600 V AC-15, 7200 VA 15 kA at 480 V AC-15, 7200 VA 30 kA at 240 V AC-15, 7200 VA 60 kA at 120 V AC-15, 7200 VA |
| contacts type and composition | 1 NC for late-break 1 NC for slow-break 2 NC |
| bezel material | chromium plated metal |
| operating position | any position |
| CAD overall width | 54 mm |
| shape of screw head | cross slotted |
| CAD overall depth | 103 mm |
| bulb base | BA 9s |
| operator position information | 2 positions |
| operator additional information | screw-on plastic mushroom |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| IP stopnja zaščite | IP66 conforming to IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | UL 508 NEMA |
| Standardi | JIS C 4520 EN/IEC 60947-1 EN/IEC 60947-5-1 EN/IEC 60947-5-4 CSA C22.2 No 14 UL 508 JIS C 852 |
| Odporno proti udarcu | 50 gn conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 7 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| NEMA degree of protection | NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 |
| electrical shock protection class | class II conforming to IEC 61140 |
| Zaščitna obdelava | TC |
