ZB5AV18B5 Schneider
ZB5AV18B5 Schneider
Opis
orange flashing light block with body/fixing collar integral LED 24V
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony XB5 |
| Izdelek ali sestavni del | complete body/light block assembly |
| Kratko ime naprave | ZB5 |
| Izvor svetlobe | protected LED |
| fixing collar material | plastic |
| Prodaja na nedeljivo količino | 1 |
| Barva vira svetlobe | orange |
| Grlo žarnice | integral LED |
| connections - terminals | screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1 screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1 |
| Komplementarno | |
| Teža izdelka | 0.022 kg |
| [Ui] Nazivna izolacijska trdnost | 600 V (pollution degree 3) conforming to EN 60947-1 |
| Kompatibilnostna koda | ZB5 |
| tightening torque | 0.8-1.2 N.m conforming to EN 60947-1 |
| [Us] rated supply voltage | 24 V 24 V AC/DC at 50/60 Hz |
| terminals description ISO n°1 | (X1-X2)PL |
| Poraba toka | 18 mA |
| Življenjska doba | 100000 h at rated voltage and 25 °C |
| Prenapetostna vzdržljivost | 1 kV conforming to IEC 61000-4-5 |
| Tip signalizacije | flashing |
| Omejitve napajalne napetosti | 19.2-30 V DC 21.6-26.4 V AC |
| customizable | no |
| CAD overall height | 42 mm |
| CAD overall width | 30 mm |
| shape of screw head | cross compatible with Philips no 1 screwdriver cross compatible with pozidriv No 1 screwdriver slotted compatible with flat Ø 4 mm screwdriver slotted compatible with flat Ø 5.5 mm screwdriver |
| CAD overall depth | 32 mm |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -40-70 °C |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | CSA RINA LROS (Lloyds register of shipping) GL BV UL listed DNV |
| Odpornost na elektromagnetna polja | 10 V/m conforming to IEC 61000-4-3 |
| Standardi | CSA C22.2 No 14 EN/IEC 60947-5-1 EN/IEC 60947-1 EN/IEC 60947-5-4 JIS C8201-5-1 UL 508 JIS C8201-1 |
| Odporno proti udarcu | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| Odpornost na elektrostatično razelektritev | 6 kV on contact (on metal parts) conforming to IEC 61000-2-6 8 kV in free air (in insulating parts) conforming to IEC 61000-2-6 |
| electrical shock protection class | class II conforming to IEC 60536 |
| Zaščitna obdelava | TH |
| Odpornost proti hitrim prehodnim pojavom | 2 kV conforming to IEC 61000-4-4 |
| Elektromagnetne emisije | class B conforming to IEC 55011 |
