ZB5AS94414 Schneider
ZB5AS94414 Schneider
Opis
red Ø40 Emergency stop, switching off head Ø22 trigger and latching key release
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony XB5 |
| Izdelek ali sestavni del | head |
| Kratko ime naprave | ZB5 |
| mounting diameter | 22 mm |
| Oblika glave signalne enote | round |
| head type | standard |
| Prodaja na nedeljivo količino | 1 |
| bezel material | dark grey plastic |
| type of operator | trigger action and mechanical latching |
| operator profile | red mushroom Ø 40 mm, unmarked |
| product destination | emergency stop push-button |
| reset | key release |
| key withdrawal position | center |
| type of keylock | Ronis 520E |
| Predstavitev naprave | basic element |
| Komplementarno | |
| Teža izdelka | 0.071 kg |
| mechanical durability | 300000 cycles |
| Kompatibilnostna koda | ZB5 |
| customizable | no |
| CAD overall height | 40 mm |
| CAD overall width | 40 mm |
| CAD overall depth | 79 mm |
| cap/operator or lens colour | red |
| Označevanje | unmarked |
| main group | E-stop |
| electrical composition code | C7 for <4 contacts using single blocks in front mounting C8 for <4 contacts using single and double blocks in front mounting C11 for <3 contacts using single blocks in front mounting C15 for <1 contacts using single blocks in front mounting SF1 for <3 contacts using single blocks in front mounting SR1 for <3 contacts using single blocks in rear mounting C10 for <4 contacts using single and double blocks in front mounting |
| group of product | emergency stop key release |
| station name | XALD 1 cut-out XALK 1 cut-out |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -40-70 °C |
| IP stopnja zaščite | IP66 conforming to IEC 60529 IP67 IP69 IP69K |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| overvoltage category | class II conforming to IEC 60536 |
| IK stopnja zaščite | IK03 conforming to IEC 50102 |
| Certifikati izdelkov | CSA BV RINA UL listed DNV LROS (Lloyds register of shipping) GL |
| Standardi | IEC 60364-5-53 CSA C22.2 No 14 UL 508 EN/IEC 60947-5-4 JIS C8201-5-1 EN/IEC 60947-5-1 EN/IEC 60947-1 EN/IEC 60947-5-5 EN/ISO 13850 EN/IEC 60204-1 GB 14048.5 JIS C8201-1 |
| Odporno proti udarcu | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| NEMA degree of protection | NEMA 13 NEMA 4X |
| Zaščitna obdelava | TH |
| resistance to high pressure washer | 7000000 Pa at 55 °C, distance : 0.1 m |
