XB4BVG6 Schneider Electric
XB4BVG6 Schneider Electric
Opis
blue complete pilot light Ø22 plain lens with integral LED 110…120V
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony XB4 |
| Izdelek ali sestavni del | pilot light |
| Kratko ime naprave | XB4 |
| [Us] Nazivna napajalna npetost | 110...120 V AC 50/60 Hz |
| Dodatne informacije za operaterja | with plain lens |
| Izvor svetlobe | protected LED |
| mounting diameter | 22 mm |
| Oblika glave signalne enote | round |
| Pokrovček/upravljalnik ali barva leče | blue |
| fixing collar material | zamak |
| head type | standard |
| Prodaja na nedeljivo količino | 1 |
| bezel material | chromium plated metal |
| Barva vira svetlobe | blue |
| Grlo žarnice | integral LED |
| Komplementarno | |
| Višina | 47 mm |
| Teža izdelka | 0.08 kg |
| Povezave - terminali | screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1 |
| [Ui] Nazivna izolacijska trdnost | 250 V (pollution degree 3) conforming to EN 60947-1 |
| Kompatibilnostna koda | XB4 |
| Širina | 30 mm |
| Globina | 54 mm |
| [Us] rated supply voltage | 110...120 V |
| terminals description ISO n°1 | (X1-X2)PL |
| Poraba toka | 14 mA |
| device presentation | complete product |
| Odpornost proti visokotlačnemu čistilniku | 7000000 Pa at 55 °C, distance : 0.1 m |
| GCR BRIDGE | XB4BVCUST04 |
| Življenjska doba | 100000 h at rated voltage and 25 °C |
| Prenapetostna vzdržljivost | 1 kV conforming to IEC 61000-4-5 |
| Tip signalizacije | steady |
| Omejitve napajalne napetosti | 100-132 V AC |
| customizable | yes |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -40-70 °C |
| IP stopnja zaščite | IP66 conforming to IEC 60529 IP67 IP69 IP69K |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| IK stopnja zaščite | IK06 conforming to IEC 50102 |
| Certifikati izdelkov | CSA UL listed |
| Odpornost na elektromagnetna polja | 10 V/m conforming to IEC 61000-4-3 |
| Standardi | EN/IEC 60947-1 JIS C8201-5-1 EN/IEC 60947-5-4 UL 508 EN/IEC 60947-5-5 EN/IEC 60947-5-1 CSA C22.2 No 14 JIS C8201-1 |
| Odporno proti udarcu | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 5 gn (f= 12-500 Hz) conforming to IEC 60068-2-6 |
| NEMA degree of protection | NEMA 13 NEMA 4X |
| Odpornost na elektrostatično razelektritev | 6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2 |
| electrical shock protection class | class I conforming to IEC 60536 |
| Zaščitna obdelava | TH |
| Odpornost proti hitrim prehodnim pojavom | 2 kV conforming to IEC 61000-4-4 |
| Elektromagnetne emisije | class B conforming to IEC 55011 |
