XT7C40PC440 Schneider
XT7C40PC440 Schneider
Opis
capacitive sensor - XT7 - 40 x 40 x 117 - plastic - Sn 15 mm - 12..48 V DC
Tehnične lastnosti
| Glavno | |
| Serija izdelka | OsiSense XT |
| [Us] Nazivna napajalna npetost | 12...48 V DC |
| size | 117 mm |
| Material | plastic |
| IP degree of protection | IP67 conforming to IEC 60529 |
| sensor design | form 40 x 40 x 117 |
| body type | plug-in body |
| electrical connection | screw clamp terminal, 4 x 1.5 mm² |
| product specific application | detection of insulated materials |
| enclosure material | plastic |
| discrete output type | PNP |
| discrete output function | 1 NC + 1 NO |
| type of output signal | discrete |
| sensor name | XT7 |
| wiring technique | 4-wire |
| [Sn] nominal sensing distance | 15 mm |
| sensor type | capacitive proximity sensor |
| detector flush mounting acceptance | flush mountable |
| output circuit type | DC |
| maximum delay response | 5 ms |
| Komplementarno | |
| Višina | 117 mm |
| Teža izdelka | 0.22 kg |
| Širina | 40 mm |
| Globina | 40 mm |
| Poraba toka | <= 10 mA |
| Omejitve napajalne napetosti | 10-58 V DC |
| cable entry | 1 entry tapped for Pg 13.5 cable gland |
| protection type | short-circuit protection |
| maximum voltage drop | <2 V (closed) |
| Označevanje | CE |
| repeat accuracy | < 0.1 x Sr |
| switching frequency | <= 100 Hz |
| sensing range | 8...15 mm |
| differential travel | < 0.2 x Sr |
| maximum delay recovery | 5 ms |
| maximum delay first up | 30 ms |
| detection face | 5 positions turret head |
| status LED | supply state indication: 1 LED (green) output state indication: 1 LED (yellow) |
| setting-up | sensitivity by potentiometer |
| maximum switching current | 200 mA |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| Certifikati izdelkov | UL CSA |
