XU2S18PP340D Schneider Electric
XU2S18PP340D Schneider Electric
Opis
security light curtain XU2-S - detection of body - Sn 8m - 12..24 VDC - M12
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Preventa Safety detection |
| Izdelek ali sestavni del | safety thru-beam pair photo-electric sensors |
| Kratko ime naprave | XU2S |
| [Sn] nominal sensing distance | 8-8 m |
| output type | 1 safety outputs OSSD PNP |
| Komplementarno | |
| Teža izdelka | 0.155 kg |
| Kompatibilnostna koda | XU2S |
| tightening torque | 24 N.m fixing nut 2 N.m connector |
| Material | nickel plated brass: case PMMA (polymethyl methacrylate): lenses |
| [Us] rated supply voltage | 12...24 V DC 10...30 V reverse polarity protection |
| Poraba toka | <= 35 mA no-load |
| electrical connection | 1 male connector M12 4 pins |
| maximum voltage drop | <1.5 V (closed) |
| Označevanje | CE |
| maximum delay response | 1 ms |
| switching frequency | 500 Hz maximum |
| maximum delay recovery | 1 ms |
| line of sight type | along case axis |
| detection system | transmitter-receiver system |
| switching capacity in mA | <= 100 mA (overload and short-circuit protection) |
| function available | built-in muting function light or dark programmable switching |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-55 °C |
| IP stopnja zaščite | IP67 conforming to EN/IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Standardi | EN/IEC 61496-1 EN/IEC 61496-2 EN/IEC 60825-1 |
| Odporno proti udarcu | 30 gn 3 axes : 3 times conforming to EN/IEC 60068-2-27 |
| Odpornost proti vibracijam | 7 gn (f= 10-55 Hz) conforming to EN/IEC 60068-2-6 |
| safety reliability data | PFH = 5.5E-7 1/h conforming to IEC 61508 with muting function PFH = 4.6E-7 1/h conforming to IEC 61508 |
| safety level | can reach PL = c associated with module XPSCM correctly wired conforming to EN/ISO 13849-1 can reach category 2 associated with module XPSCM correctly wired conforming to EN/ISO 13849-1 type 2 conforming to IEC 61496-1-2 |
