XU2S18KP340WL5T Schneider
XU2S18KP340WL5T Schneider
Opis
light curtain transmitter XU2-S - detection of body - 12..24 V - 3 x 0.34 mm²
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Preventa Safety detection |
| Izdelek ali sestavni del | safety thru-beam transmitter photo-electric sensors |
| Kratko ime naprave | XU2S |
| Združljivost izdelkov | XPSCM1144P XPSCM1144 |
| [Sn] nominal sensing distance | 8-8 m |
| Komplementarno | |
| Teža izdelka | 0.235 kg |
| Kompatibilnostna koda | XU2S |
| tightening torque | 24 N.m fixing nut |
| Material | nickel plated brass: case PMMA (polymethyl methacrylate): lenses |
| [Us] rated supply voltage | 12...24 V DC (10...30 V)against reverse polarity |
| Poraba toka | <= 35 mA no-load |
| electrical connection | pre-cabled |
| cable outer diameter | 5 mm |
| Označevanje | CE |
| cable length | 5 m |
| cable composition | 3 x 0.34 mm² |
| line of sight type | 90° to case axis |
| detection system | transmitter-receiver system |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-55 °C |
| IP stopnja zaščite | IP67 conforming to EN/IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Odporno proti udarcu | 30 gn 3 axes : 3 times conforming to EN/IEC 60068-2-27 |
| Odpornost proti vibracijam | 7 gn (f= 10-55 Hz) conforming to EN/IEC 60068-2-6 |
