XCSDMC7905 Schneider Electric
XCSDMC7905 Schneider Electric
Opis
coded magnetic switch XCSDMC - 2 NC - staggered - 5m
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Preventa Safety detection |
| Izdelek ali sestavni del | coded magnetic switch |
| size | 51 x 16 x 7 mm |
| Material | plastic |
| contacts type and composition | 2 NC |
| contact operation | staggered |
| number of poles | 2 |
| electrical connection | pre-cabled |
| Dolžina kabla | 5 m |
| [Ue] rated operational voltage | 24 V DC |
| component name | XCSDMC |
| design | rectangular, compact |
| [Ui] rated insulation voltage | 100 V DC |
| cable composition | 4 x 0.25 mm² |
| approach directions | 3 directions |
| Komplementarno | |
| Višina | 51 mm |
| Teža izdelka | 0.101 kg |
| electrical durability | 1200000 cycles |
| Širina | 16 mm |
| Globina | 7 mm |
| contacts material | rhodium |
| short-circuit protection | 500 mA external cartridge fuse type gG (gl) |
| breaking capacity | 10 VA |
| enclosure material | thermoplastic PBT |
| switching frequency | 150 Hz |
| switching capacity in mA | 0.1...100 mA |
| insulation resistance | 1000 MOhm |
| safety reliability data | B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear |
| safety level | can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1 can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1 can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508 |
| [Sa] assured operating distance | 5 mm |
| maximum [Ie] rated operational current | 100 mA |
| [Sar] assured tripping distance | 15 mm |
| resistance across terminals | 10 Ohm |
| maximum switching voltage | 100 V DC |
| cable material | PVC |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-85 °C |
| IP stopnja zaščite | IP66 conforming to IEC 60529 IP67 conforming to IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-85 °C |
| Certifikati izdelkov | BG UL CSA |
| Standardi | CSA C22.2 No 14 EN/IEC 60947-5-1 EN/ISO 12100 EN/IEC 60204-1 UL 508 ISO 14119 |
| Odporno proti udarcu | 30 gn for 11 ms conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6 |
| electrical shock protection class | class II conforming to EN/IEC 61140 |
| Zaščitna obdelava | TH |
| maximum sensitivity to magnetic fields | 0.3 mT |
