XUK9ARCNL10 Schneider Electric
XUK9ARCNL10 Schneider Electric
Opis
photo-electric sensor - XUK - polarised - Sn 5m - 24..240VAC/DC - cable 10m
Tehnične lastnosti
| Glavno | |
| Serija izdelka | OsiSense XU |
| Material | plastic |
| sensor design | compact 50 x 50 |
| series name | general purpose single mode |
| electrical connection | cable |
| product specific application | - |
| discrete output function | 1 C/O |
| type of output signal | discrete |
| Dolžina kabla | 10 m |
| sensor name | XUK |
| wiring technique | 5-wire |
| [Sn] nominal sensing distance | 6-6 m polarised reflex need reflector XUZC50 |
| emission | red polarised reflex |
| sensing range | > 1...5 m |
| detection system | polarised reflex |
| supply circuit type | AC/DC |
| electronic sensor type | photo-electric sensor |
| Komplementarno | |
| Višina | 50 mm |
| Teža izdelka | 0.19 kg |
| electrical durability | 500000 cycles, cos f = 1 , operating rate <60 cyc/mn at 250 V |
| Širina | 18 mm |
| Globina | 50 mm |
| [Us] rated supply voltage | 24...240 V AC/DC |
| Poraba toka | <= 35 mA no-load |
| Omejitve napajalne napetosti | 20-264 V AC 20-264 V DC |
| maximum voltage drop | <1.5 V (closed state) |
| enclosure material | PBT |
| maximum delay response | 25 ms |
| switching frequency | <= 20 Hz |
| maximum delay recovery | 25 ms |
| maximum delay first up | 60 ms |
| wire insulation material | PVC |
| status LED | 1 LED (yellow) for output state 1 LED (green) for supply |
| lens material | PMMA |
| setting-up | without sensitivity adjustment |
| maximum sensing distance | 8 m polarised reflex |
| switching capacity in mA | 3 A (cos φ = 1 for 0.5 million cycles at 1 operating cycle per second at 250 V) |
| output type | relay |
| maximum power consumption in W | 2 W AC |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-55 °C |
| IP stopnja zaščite | IP65 double insulation conforming to IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | CSA UL CE |
| Odporno proti udarcu | 30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 7 gn, amplitude = +/- 1.5 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
