TSXDSZ08T2K Schneider

TSX Micro - 8 discret output DC

Glavno
Serija izdelka	Modicon TSX Micro automation platform
Izdelek ali sestavni del	discrete output module
discrete output voltage	24 V DC
discrete output number	8 1 HE-10 connector
discrete output logic	positive
discrete output current	0.5 mA
Komplementarno
Teža izdelka	0.18 kg
Poraba toka	38 mA
switching frequency	< 0.6/LI² Hz
response time	< 0.5 ms at state 1 < 0.5 ms at state 0
maximum leakage current	0.5 mA at state 0
power dissipation in W	3.5 W by module 0.15 W by channel
output overvoltage protection	by zener diode
output short-circuit protection	thermal circuit breaker current limiter
[Ures] residual voltage	0.3 V
reverse polarity protection	reverse diode on power supply
load impedance ohmic	48 Ohm
paralleling of outputs	yes : 2 maximum
output voltage limits	19...30 V
isolation voltage	1500 V for 1 s
output current limits	0.625 A
