TM4ES4 Schneider Electric
TM4ES4 Schneider Electric
Opis
module network TM4 4 Ethernet switchs
Tehnične lastnosti
| Glavno | |
| Izdelek ali sestavni del | Ethernet unmanaged switch |
| Komplementarno | |
| Višina | 90 mm |
| mounting support | top hat type TH35-15 rail conforming to IEC 60715 top hat type TH35-7.5 rail conforming to IEC 60715 plate or panel with fixing kit |
| Teža izdelka | 0.125 kg |
| local signalling | 1 LED (green)PWR: 1 LED per channel (green/yellow)Ethernet link: 1 LED per channel (green)Ethernet port activity: |
| Širina | 25 mm |
| Globina | 90 mm |
| Poraba toka | 360 mA at 5 V DC for communication bus |
| Prenapetostna vzdržljivost | 1 kV power lines (DC) common mode conforming to EN/IEC 61000-4-5 2 kV power lines (AC) common mode conforming to EN/IEC 61000-4-5 2 kV relay output common mode conforming to EN/IEC 61000-4-5 1 kV I/O common mode conforming to EN/IEC 61000-4-5 1 kV shielded cable common mode conforming to EN/IEC 61000-4-5 0.5 kV power lines (DC) differential mode conforming to EN/IEC 61000-4-5 1 kV power lines (AC) differential mode conforming to EN/IEC 61000-4-5 1 kV relay output differential mode conforming to EN/IEC 61000-4-5 0.5 kV I/O differential mode conforming to EN/IEC 61000-4-5 |
| product compatibility | Modicon M241 logic controller Modicon M251 logic controller |
| electrical connection | RJ45 4 connectors for connecting Ethernet network screw connector terminal for connecting the functional ground |
| Označevanje | CE |
| transmission rate | 10/100 Mbit/s |
| range compatibility | Modicon M251 Modicon M241 |
| communication port protocol | Ethernet IP/Modbus TCP TCP (Transmission Control Protocol) UDP (User Datagram Protocol) SNMP |
| communication service | Modbus TCP server Modbus TCP slave device FTP NGVL monitoring IEC VAR ACCESS programming SNMP Modbus TCP client downloading updating firmware Ethernet/IP slave device DHCP client |
| integrated connection type | Ethernet: 4 RJ45 connector |
| port Ethernet | 10BASE-T/100BASE-TX - 4 port(s) copper cable |
| web services | web server |
| maximum number of connections | 8 Modbus server 16 Ethernet/IP device |
| redundancy | no |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -10-55 °C horizontal installation -10-50 °C vertical installation |
| IP stopnja zaščite | IP20 with protective cover in place |
| Stopnja onesnaženosti | 2 |
| Temperatura okoliškega zraka za skladiščenje | -25-70 °C |
| relative humidity | 10-95 %, without condensation (in operation) 10-95 %, without condensation (in storage) |
| Nadmorska višina delovanja | 0...2000 m |
| Certifikati izdelkov | cULus C-Tick |
| Odpornost na elektromagnetna polja | 10 V/m 80 MHz...1 GHz conforming to EN/IEC 61000-4-3 3 V/m 1.4 GHz...2 GHz conforming to EN/IEC 61000-4-3 1 V/m 2...2.7 GHz conforming to EN/IEC 61000-4-3 |
| Standardi | UL 508 EN/IEC 61131-2 |
| Odporno proti udarcu | 15 gn for 11 ms |
| Odpornost proti vibracijam | 1 mm at 5-13.2 Hz on symmetrical rail 3 gn at 8.7-150 Hz on symmetrical rail 1 mm at 5-13.2 Hz on panel mounting 0.7 gn at 13.2-100 Hz on panel mounting |
| Odpornost na elektrostatično razelektritev | 8 kV in air conforming to EN/IEC 61000-4-2 4 kV on contact conforming to EN/IEC 61000-4-2 8 kV in air conforming to Marine specification (LR, ABS, DNV, GL) 6 kV on contact conforming to Marine specification (LR, ABS, DNV, GL) |
| Odpornost proti hitrim prehodnim pojavom | 2 kV (power lines) conforming to EN/IEC 61000-4-4 2 kV (relay output) conforming to EN/IEC 61000-4-4 1.5 kV (I/O) conforming to EN/IEC 61000-4-4 1 kV (Ethernet line) conforming to EN/IEC 61000-4-4 1 kV (serial link) conforming to EN/IEC 61000-4-4 |
| Elektromagnetne emisije | conducted emissions - test level: 79 dBμV/m QP/66 dBμV/m AV ( power lines (AC)) at 0.15-0.5 MHz conforming to EN/IEC 55011 radiated emissions - test level: 80...50 dμV/m QP at 150-30000 kHz conforming to Marine specification (LR, ABS, DNV, GL) radiated emissions - test level: 54 dBμV/m QP at 100-2000 MHz conforming to Marine specification (LR, ABS, DNV, GL) conducted emissions - test level: 73 dBμV/m QP/60 dBμV/m AV ( power lines (AC)) at 0.5-300 MHz conforming to EN/IEC 55011 conducted emissions - test level: 120...69 dBµV/m QP ( power lines) at 10-150 kHz conforming to EN/IEC 55011 conducted emissions - test level: 63 dBμV/m QP ( power lines) at 1.5-30 MHz conforming to EN/IEC 55011 radiated emissions - test level: 40 dBμV/m QP class A at 30-230 MHz conforming to EN/IEC 55011 radiated emissions - test level: 60...54 dBμV/m QP at 30-100 MHz conforming to Marine specification (LR, ABS, DNV, GL) radiated emissions - test level: 24 dBμV/m QP at 156-165 MHz conforming to Marine specification (LR, ABS, DNV, GL) conducted emissions - test level: 79...63 dBμV/m QP ( power lines) at 150-1500 kHz conforming to EN/IEC 55011 radiated emissions - test level: 47 dBμV/m QP class A at 230-1000 MHz conforming to EN/IEC 55011 |
| resistance to conducted disturbances | 10 V 0.15...80 MHz conforming to EN/IEC 61000-4-6 3 V 0.1...80 MHz conforming to Marine specification (LR, ABS, DNV, GL) 10 V spot frequency (2, 3, 4, 6.2, 8.2, 12.6, 16.5, 18.8, 22, 25 MHz) conforming to Marine specification (LR, ABS, DNV, GL) |
| storage altitude | 0-3000 m |
