BMXDDI1604T Schneider Electric
BMXDDI1604T Schneider Electric
Opis
discrete input module X80 - 16 inputs - 125 V DC
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Modicon X80 |
| Izdelek ali sestavni del | discrete input module |
| product specific application | extended temperature |
| discrete input number | 16 |
| discrete input voltage | 125 V DC, discrete input logic: positive |
| discrete input current | 2.4 mA |
| discrete input type | isolated |
| input compatibility | with 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2 |
| input type | current sink (logic positive) |
| Komplementarno | |
| Teža izdelka | 0.115 kg |
| Poraba toka | <= 107 mA at 3.3 V DC |
| protection type | reverse polarity protection fast blow 1 external fuse per group of channel0.5 A |
| voltage state 0 guaranteed | <= 36 V |
| voltage state 1 guaranteed | >= 88 V |
| status LED | 1 LED (green)module operating (RUN): 1 LED per channel (green)channel diagnostic: 1 LED (red)module error (ERR): 1 LED (red)module I/O: |
| insulation resistance | > 10 MOhm 500 V DC |
| response time on output | 8...30 ms on appearance |
| typical current consumption | 76 mA at 3.3 V DC |
| maximum power dissipation in W | 8.5 W |
| voltage detection threshold | < 80 V DC sensor fault > 100 V DC sensor OK |
| current state 1 guaranteed | >= 2 mA |
| current state 0 guaranteed | <= 0.5 mA |
| input impedance | 50000 Ohm |
| sensor power supply | 88-150 V |
| DC typical filtering time | 5 ms |
| DC maximum filtering time | 9 ms |
| paralleling of inputs | yes |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| IP stopnja zaščite | IP20 |
| Temperatura okoliškega zraka za skladiščenje | -40-85 °C |
| relative humidity | 5-95 % at 55-55 °C without condensation |
| Nadmorska višina delovanja | 0...2000 m 2000...5000 m with derating factor |
| Certifikati izdelkov | CSA EAC Merchant Navy RCM CE UL |
| Standardi | EN 61131-2 EN 61000-6-4 EN 61000-6-2 EN 61010-2-201 |
| Odporno proti udarcu | 30 gn |
| Odpornost proti vibracijam | 3 gn |
| Zaščitna obdelava | conformal coating |
| environmental characteristic | gas resistant class Gx gas resistant class 3C4 dust resistant class 3S4 sand resistant class 3S4 salt resistant level 2 mold growth resistant class 3B2 fungal spore resistant class 3B2 |
| directives | 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility 2012/19/EU - WEEE directive |
| dielectric strength | 2500 V AC at 50/60 Hz 1 minute, primary/secondary |
