BMXDAI0805 Schneider Electric
BMXDAI0805 Schneider Electric
Opis
discrete input module X80 - 8 inputs - 200...240 V AC
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Modicon X80 |
| Izdelek ali sestavni del | discrete input module |
| discrete input number | 8 |
| discrete input voltage | 200...240 V AC |
| discrete input current | 10.4 mA |
| discrete input type | isolated |
| input compatibility | with 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2 |
| input type | capacitive |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Teža izdelka | 0.12 kg |
| Poraba toka | <= 126 mA at 3.3 V DC <= 154.8 mA at 24 V DC |
| protection type | 1 external fuse per group of channel0.5 A fast blow |
| voltage state 0 guaranteed | <= 40 V |
| voltage state 1 guaranteed | >= 159 V |
| status LED | 1 LED (green)module operating (RUN): 1 LED per channel (green)channel diagnostic: 1 LED (red)module error (ERR): 1 LED (red)module I/O: |
| insulation resistance | > 10 MOhm 500 V DC |
| network frequency limits | 47-63 Hz |
| typical current consumption | 76 mA at 3.3 V DC 93.6 mA at 24 V DC |
| maximum power dissipation in W | 4.73 W |
| voltage detection threshold | > 164 V AC sensor OK < 80 V AC sensor fault |
| current state 1 guaranteed | >= 6 mA |
| current state 0 guaranteed | <= 4 mA |
| input impedance | 21000 Ohm |
| sensor power supply | 170-264 V |
| AC deactivation filtering time | 20 ms |
| AC activation filtering time | 10 ms |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | 0-60 °C |
| IP stopnja zaščite | IP20 |
| Temperatura okoliškega zraka za skladiščenje | -40-85 °C |
| relative humidity | 5-95 % at 55-55 °C without condensation |
| Nadmorska višina delovanja | 0...2000 m 2000...5000 m with derating factor |
| Certifikati izdelkov | UL RCM CE Merchant Navy EAC CSA |
| Standardi | EN 61131-2 EN 61000-6-4 EN 61000-6-2 EN 61010-2-201 |
| Odporno proti udarcu | 30 gn |
| Odpornost proti vibracijam | 3 gn |
| Zaščitna obdelava | TC |
| directives | 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility 2012/19/EU - WEEE directive |
| dielectric strength | 1500 V AC at 50/60 Hz 1 min |
