LG8K06M705 Schneider
LG8K06M705 Schneider
Opis
TeSys LG - enclosed DOL reversing starter - 0.63...1 A - 220/230 V AC coil
Tehnične lastnosti
| Glavno | |
| Izdelek ali sestavni del | enclosed DOL reversing starter |
| product name | TeSys LG |
| utilisation category | AC-3 |
| Skupina izdelkov | TeSys |
| Aplikacija naprave | safety |
| Kratko ime naprave | LG8K |
| device composition | reversing contactor circuit-breaker |
| [Uc] Krmilna napetost | 220/230 V AC 50/60 Hz |
| motor power kW | 0.12 kW at 220/230 V AC 50/60 Hz 0.25 kW at 400/415 V AC 50/60 Hz 0.25 kW at 440 V AC 50/60 Hz |
| thermal protection adjustment range | 0.63-1 A |
| control type | push-button stop black O selector switch 2 positions start black I-II mushroom head push-button emergency stop red |
| Komplementarno | |
| Višina | 165 mm |
| Teža izdelka | 1.64 kg |
| Kompatibilnostna koda | LG8K |
| Širina | 175 mm |
| Globina | 146 mm |
| cable entry number | 4 2 Pg 13 + 2 Pg 16 top 4 2 Pg 13 + 2 Pg 16 bottom |
| Okolje | |
| IP stopnja zaščite | IP55 conforming to IEC 60529 (for enclosure) |
| IK stopnja zaščite | IK07 conforming to IEC 60529 |
| Standardi | IEC 60204-1 IEC 60947-4-1 |
| environmental characteristic | standard environment |
| material | polycarbonate |
