TeSys K - star delta starter - 3 x 3P (3 NO) - 9 A - 230 V AC coil
Tehnične lastnosti
| Glavno | |
| Serija izdelka | TeSys K |
| standards | IEC 60947 NF C 63-110 VDE 0660 |
| Izdelek ali sestavni del | star delta starter |
| product name | TeSys K |
| utilisation category | AC-3 |
| Skupina izdelkov | TeSys |
| Opis polov | 3 x 3P |
| Kratko ime naprave | LC3K |
| [Ie] rated operational current | 9 A (at <50 °C) at <= 440 V AC AC-3 for power circuit |
| [Uc] Krmilna napetost | 230 V AC 50/60 Hz |
| [Ue] rated operational voltage | power circuit: <= 690 V AC 25...400 Hz |
| product certifications | UL CSA |
| motor power kW | 4 kW at 220/230 V AC 50/60 Hz 7.5 kW at 380/400 V AC 50/60 Hz 7.5 kW at 415 V AC 50/60 Hz 7.5 kW at 440 V AC 50/60 Hz |
| mounting support | rail |
| control circuit type | AC at 50/60 Hz |
| contactor application | motor control |
| [Uimp] rated impulse withstand voltage | 8 kV |
| pole contact composition | 3 x 3 NO |
| electrical durability | 1.3 Mcycles 9 A AC-3 at Ue <= 440 V |
| overvoltage category | III |
| [Ui] rated insulation voltage | power circuit: 750 V conforming to VDE 0110 group C signalling circuit: 690 V conforming to NF C 20-040 signalling circuit: 600 V CSA 22-2 certified signalling circuit: 600 V UL 508 certified power circuit: 690 V conforming to IEC 60947 power circuit: 690 V conforming to BS 5424 power circuit: 690 V conforming to NF C 20-040 power circuit: 600 V CSA 22-2 certified power circuit: 600 V UL 508 certified signalling circuit: 750 V conforming to VDE 0110 group C signalling circuit: 690 V conforming to IEC 60947 signalling circuit: 690 V conforming to BS 5424 |
| Predstavitev naprave | pre-wired |
| auxiliary contact composition | 1 NC for KM1 star contactor |
| interlocking type | mechanical |
| Komplementarno | |
| Višina | 110 mm |
| Teža izdelka | 0.74 kg |
| Povezave - terminali | screw clamp terminals 1 1.5-4 mm² - cable stiffness: solid screw clamp terminals 1 0.75-4 mm² - cable stiffness: flexible without cable end screw clamp terminals 1 0.34-2.5 mm² - cable stiffness: flexible with cable end screw clamp terminals 2 1.5-4 mm² - cable stiffness: solid screw clamp terminals 2 0.75-4 mm² - cable stiffness: flexible without cable end screw clamp terminals 2 0.34-1.5 mm² - cable stiffness: flexible with cable end |
| mechanical durability | 10 Mcycles |
| Širina | 150 mm |
| Globina | 94 mm |
| tightening torque | 1.3 N.m - on screw clamp terminals - with screwdriver Philips No 2 1.3 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm |
| maximum operating rate | 12 cyc/h 60 °C |
| minimum switching current | 5 mA for signalling circuit |
| Omejitve napetosti regulacijskega vezja | operational: 0.8...1.15 Uc (at <50 °C) drop-out: 0.2...0.75 Uc (at <50 °C) |
| Inrush power in VA | 30-30 VA (at 20 °C) |
| Tehnologija tuljave | without built-in suppressor module |
| Hold-in power consumption in VA | 4.5-4.5 VA (at 20 °C) |
| heat dissipation | 1.3-1.3 W |
| auxiliary contacts type | mechanically linked conforming to IEC 60947-5-1 3 x 1 NO + 1 NC mirror contact conforming to IEC 60947-4-1 3 x 1 NC |
| switching voltage | 17 V for signalling circuit |
| starting time | 30 s |
| Okolje | |
| IP stopnja zaščite | IP20 conforming to VDE 0106 |
| Temperatura okoliškega zraka za skladiščenje | -50-80 °C |
| Nadmorska višina delovanja | 2000 m without |
| Zaščitna obdelava | TC conforming to IEC 60068 TC conforming to DIN 50016 |
| flame retardance | V1 conforming to UL 94 requirement 2 conforming to NF F 16-101 requirement 2 conforming to NF F 16-102 |
| insulation resistance | > 10 MOhm for signalling circuit |
| mechanical robustness | vibrations contactor open: 2 Gn, 5...300 Hz vibrations contactor closed: 4 Gn, 5...300 Hz shocks contactor closed, on X axis: 10 Gn for 11 ms shocks contactor opened, on X axis: 6 Gn for 11 ms shocks contactor closed, on Y axis: 15 Gn for 11 ms shocks contactor opened, on Y axis: 10 Gn for 11 ms shocks contactor closed, on Z axis: 15 Gn for 11 ms shocks contactor opened, on Z axis: 10 Gn for 11 ms |
