LC1K06105M7 Schneider
LC1K06105M7 Schneider
Opis
TeSys K contactor - 3P - AC-3
Tehnične lastnosti
| Glavno | |
| Serija izdelka | TeSys K |
| Izdelek ali sestavni del | contactor |
| product name | TeSys K |
| Skupina izdelkov | TeSys |
| Aplikacija naprave | control |
| Kratko ime naprave | LC1K |
| contactor application | motor control |
| Komplementarno | |
| Višina | 58 mm |
| mounting support | printed circuit boards |
| Teža izdelka | 0.18 kg |
| Povezave - terminali | solder pins - busbar cross section: 1.5 x 0.9 mm |
| [Ui] Nazivna izolacijska trdnost | power circuit: 600 V conforming to UL 508 power circuit: 690 V conforming to IEC 60947-4-1 signalling circuit: 690 V conforming to IEC 60947-4-1 signalling circuit: 690 V conforming to IEC 60947-5-1 signalling circuit: 600 V conforming to UL 508 power circuit: 600 V conforming to CSA C22.2 No 14 signalling circuit: 600 V conforming to CSA C22.2 No 14 |
| electrical durability | 1.3 Mcycles 6 A AC-3 at Ue <= 440 V |
| mechanical durability | 10 Mcycles |
| Kompatibilnostna koda | LC1K |
| [Uimp] rated impulse withstand voltage | 8 kV |
| Širina | 45 mm |
| Globina | 57 mm |
| [Ue] rated operational voltage | power circuit: 690 V AC 50/60 Hz signalling circuit: <= 690 V AC 50/60 Hz |
| [Ith] conventional free air thermal current | 20 A (at 50 °C) for power circuit 10 A (at 50 °C) for signalling circuit |
| rated breaking capacity | 110 A at 415 V conforming to IEC 60947 110 A at 440 V conforming to IEC 60947 80 A at 500 V conforming to IEC 60947 110 A at 220...230 V conforming to IEC 60947 110 A at 380...400 V conforming to IEC 60947 70 A at 660...690 V conforming to IEC 60947 |
| [Ie] rated operational current | 6 A at <= 440 V AC AC-3 for power circuit |
| [Uc] control circuit voltage | 220...230 V AC 50/60 Hz |
| [Icw] rated short-time withstand current | 90 A 50 °C - 1 s for power circuit 85 A 50 °C - 5 s for power circuit 80 A 50 °C - 10 s for power circuit 60 A 50 °C - 30 s for power circuit 45 A 50 °C - 1 min for power circuit 40 A 50 °C - 3 min for power circuit 20 A 50 °C - >= 15 min for power circuit 80 A - 1 s for signalling circuit 90 A - 500 ms for signalling circuit 110 A - 100 ms for signalling circuit |
| maximum operating rate | 3600 cyc/h |
| insulation resistance | > 10 MOhm for signalling circuit |
| poles description | 3P |
| overvoltage category | III |
| minimum switching current | 5 mA for signalling circuit |
| Omejitve napetosti regulacijskega vezja | operational: 0.8...1.15 Uc (at <50 °C) drop-out: 0.2...0.75 Uc (at <50 °C) |
| Inrush power in VA | 30-30 VA (at 20 °C) |
| Hold-in power consumption in VA | 4.5-4.5 VA (at 20 °C) |
| heat dissipation | 1.3-1.3 W |
| auxiliary contact composition | 1 NO |
| minimum switching voltage | 17 V for signalling circuit |
| signalling circuit frequency | <= 400 Hz |
| auxiliary contacts type | type instantaneous 1 NO |
| average impedance | 3 mOhm - Ith 20 A 50 Hz for power circuit |
| associated fuse rating | 25 A gG at <= 440 V for power circuit 25 A aM for power circuit 10 A gG for signalling circuit conforming to IEC 60947 10 A gG for signalling circuit conforming to VDE 0660 |
| operating time | 10...20 ms coil de-energisation and NO opening 10...20 ms coil energisation and NO closing |
| motor power kW | 1.5 kW at 220...230 V AC 50/60 Hz AC-3 2.2 kW at 380...415 V AC 50/60 Hz AC-3 3 kW at 440 V AC 50/60 Hz AC-3 3 kW at 480 V AC 50/60 Hz AC-3 3 kW at 500...600 V AC 50/60 Hz AC-3 3 kW at 660...690 V AC 50/60 Hz AC-3 1.5 kW at 400 V AC 50/60 Hz AC-4 |
| utilisation category | AC-4 AC-3 |
| mechanical robustness | shocks contactor closed, on X axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 shocks contactor closed, on Y axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 shocks contactor closed, on Z axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 shocks contactor opened, on X axis: 6 Gn for 11 ms conforming to IEC 60068-2-27 shocks contactor opened, on Y axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 shocks contactor opened, on Z axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 vibrations contactor closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 vibrations contactor opened: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| non overlap distance | 0.5 mm |
| control circuit type | AC at 50/60 Hz |
| safety reliability level | B10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1 |
| Irms rated making capacity | 110 A AC for power circuit conforming to NF C 63-110 110 A AC for power circuit conforming to IEC 60947 110 A AC for signalling circuit conforming to IEC 60947 |
| pole contact composition | 3 NO |
| Okolje | |
| IP stopnja zaščite | IP2x conforming to VDE 0106 |
| Temperatura okoliškega zraka za skladiščenje | -50-80 °C |
| Nadmorska višina delovanja | 2000 m without |
| Certifikati izdelkov | UL CSA |
| Standardi | BS 5424 IEC 60947 NF C 63-110 VDE 0660 |
| Zaščitna obdelava | TC conforming to IEC 60068 TC conforming to DIN 50016 |
| flame retardance | V1 conforming to UL 94 requirement 2 conforming to NF F 16-101 requirement 2 conforming to NF F 16-102 |
