GVAD0110 Schneider Electric
GVAD0110 Schneider Electric
Opis
TeSys GV2 & GV3 - auxiliary contact - 1 NO + 1 NC (fault)
Tehnične lastnosti
| Glavno | |
| Serija izdelka | TeSys GV3 TeSys GV2 |
| Izdelek ali sestavni del | auxiliary contact block |
| Skupina izdelkov | TeSys |
| Kratko ime naprave | GVAD |
| Združljivost izdelkov | GV2ME GV2L GV3P GV2P GV3L GV2LE GV2RT |
| Lokacija montaže | left side |
| connections - terminals | screw clamp terminals 1 cable(s) 1-2.5 mm²solid screw clamp terminals 2 cable(s) 1-2.5 mm²solid screw clamp terminals 1 cable(s) 0.75-2.5 mm²flexible without cable end screw clamp terminals 2 cable(s) 0.75-2.5 mm²flexible without cable end screw clamp terminals 2 cable(s) 0.75-1.5 mm²flexible with cable end screw clamp terminals 1 cable(s) 0.75-1.5 mm²flexible with cable end |
| pole contact composition | 1 NO + 1 NC |
| auxiliary contacts operation | fault signal 1 NC |
| Komplementarno | |
| Višina | 89 mm |
| Teža izdelka | 0.055 kg |
| [Ui] Nazivna izolacijska trdnost | 690 V conforming to IEC 60947-1 300 V conforming to UL 508 300 V conforming to CSA C22.2 No 14 |
| mechanical durability | 100000 cycles |
| Kompatibilnostna koda | GVAD |
| Širina | 9.3 mm |
| Globina | 66 mm |
| tightening torque | 1.4 N.m - on screw clamp terminals |
| [Ue] rated operational voltage | 48...690 V AC 24...240 V DC |
| protection type | GB2CB... circuit breaker gG fuse 10 A |
| [Ith] conventional free air thermal current | 6 A 2.5 A for fault signalling |
| minimum switching current | 5 mA |
| minimum switching voltage | 17 V |
| rated operational power in W | 120 W at 240 V DC-13 - electrical durability: 100000 cycles 140 W at 110 V DC-13 - electrical durability: 100000 cycles 140 W at 24 V DC-13 - electrical durability: 100000 cycles 180 W at 60 V DC-13 - electrical durability: 100000 cycles 240 W at 48 V DC-13 - electrical durability: 100000 cycles 15 W at 48 V DC-13 - electrical durability: 1000 cycles 24 W at 24 V DC-13 - electrical durability: 1000 cycles 9 W at 60 V DC-13 - electrical durability: 1000 cycles |
| rated operational power in VA | 300 VA at 48-48 V AC-15 - electrical durability: 100000 cycles 414 VA at 690-690 V AC-15 - electrical durability: 100000 cycles 500 VA at 110-127 V AC-15 - electrical durability: 100000 cycles 500 VA at 500-500 V AC-15 - electrical durability: 100000 cycles 650 VA at 440-440 V AC-15 - electrical durability: 100000 cycles 720 VA at 230-240 V AC-15 - electrical durability: 100000 cycles 850 VA at 380-415 V AC-15 - electrical durability: 100000 cycles 36 VA at 24-24 V AC-14 - electrical durability: 1000 cycles 48 VA at 48-48 V AC-14 - electrical durability: 1000 cycles 72 VA at 110-127 V AC-14 - electrical durability: 1000 cycles |
| Okolje | |
| environmental characteristic | normal environment |
