XF9D651 Schneider Electric
XF9D651 Schneider Electric
Opis
overtravel power limit switch - manual reset - 4P - 130/65 A - 2/3P scheme
Tehnične lastnosti
| Glavno | |
| Serija izdelka | XR and XF |
| Izdelek ali sestavni del | overtravel limit switches |
| Kratko ime naprave | XF9 |
| type of operator | manual latching, restricted by a padlockable device |
| [Ie] rated operational current | , Ie = 130 A 2-pole scheme AC-3, Ie = 65 A 3-pole scheme |
| Material | aluminium alloy: case |
| number of poles | 4 |
| product specific application | safety of hoisting equipment |
| electrical circuit type | power circuit |
| Komplementarno | |
| Teža izdelka | 3.83 kg |
| [Ui] Nazivna izolacijska trdnost | 500 V conforming to IEC 158-1 500 V conforming to IEC 947-4 500 V conforming to VDE 0110 group C 600 V conforming to CSA C22.2 No 14 |
| Kompatibilnostna koda | XF9 |
| cable cross section | 1 flexible cable 2.5-16 mm² with cable end 1 flexible cable 2.5-25 mm² without cable end 1 solid cable 2.5-25 mm² without cable end 2 flexible cable 2.5-16 mm² without cable end 2 flexible cable 2.5-6 mm² with cable end 2 solid cable 4-16 mm² without cable end |
| cable entry | 3 entries tapped for Pg 29 cable gland |
| rated breaking capacity | 1000 kA at 500 V 2-pole scheme conforming to IEC 158-1 630 kA at 660 V 2-pole scheme conforming to IEC 158-1 |
| contacts type and composition | without auxiliary contact block |
| contact operation | snap action |
| [Ithe] conventional enclosed thermal current | 160 A at -25-40 °C 2-pole scheme 80 A at -25-40 °C 3-pole scheme |
| switch actuation | horizontal approach |
| maximum displacement angle | 75 ° |
| reset | manual reset |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-70 °C |
| IP stopnja zaščite | IP54 conforming to EN/IEC 60529 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | CSA |
| Standardi | VDE 0660 IEC 947-4 IEC 947-1 IEC 158-1 NF C 63-110 |
| Zaščitna obdelava | TC |
