XPEM211EX Schneider Electric
XPEM211EX Schneider Electric
Opis
foot switch XPE-M - w/o cover - metal - blue - 2NC+1NO - protection against dust
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Harmony XPE |
| Izdelek ali sestavni del | foot switch |
| Kratko ime naprave | XPEM |
| Material | metal |
| contacts type and composition | 2 NC + 1 NO |
| contact operation | 2 steps |
| colour | blue |
| protective cover | without |
| trigger mechanism | without trigger mechanism |
| foot switch type | single foot switch |
| Komplementarno | |
| Višina | 59 mm |
| Povezave - terminali | screw clamp terminal, <= 1 x 2.5 mm² with or without cable end screw clamp terminal, <= 2 x 1.5 mm² with or without cable end |
| [Ui] Nazivna izolacijska trdnost | 300 V conforming to UL 508 500 V (pollution degree 3) conforming to EN/IEC 60947-1 500 V (pollution degree 3) conforming to NF C 20-040 group C 500 V (pollution degree 3) conforming to VDE 0110 group C 300 V conforming to CSA C22.2 No 14 |
| mechanical durability | 5000000 cycles |
| Kompatibilnostna koda | XPEM |
| Širina | 104 mm |
| Globina | 172 mm |
| cable entry | 2 tapped entries for Pg 16 |
| short-circuit protection | 10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1 10 A cartridge fuse type gG conforming to VDE 0660-200 |
| positive opening | with conforming to EN/IEC 60947-5-1 appendix K |
| [Ie] rated operational current | 3 A at 240 V, AC-15, A300 0.27 A at 250 V, DC-13, Q300 conforming to EN/IEC 60947-5-1 appendix A |
| Označevanje | II2 D-Ex tD A21 IP65 T85°C |
| maximum resistance across terminals | 0.025 mOhm conforming to IEC 60255-7 category 3 0.025 mOhm conforming to NF C 93-050 method A |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -20-60 °C |
| IP stopnja zaščite | IP66 |
| Temperatura okoliškega zraka za skladiščenje | -40-70 °C |
| Certifikati izdelkov | INERIS 04ATEX0025 |
| Standardi | EN 50281-1-1 IEC 61241-1 ATEX D 94/9/CE EN 50014 IEC 61241-0 |
| Odporno proti udarcu | 150 gn conforming to NF E 09-031 20 gn conforming to IEC 60068-2-27 |
| Odpornost proti vibracijam | 15 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| electrical shock protection class | class I conforming to EN/IEC 61140 class I conforming to NF C 20-030 |
| Zaščitna obdelava | TC |
| dust zone | zone 21 - 22 |
