A9N18560 Schneider Electric
A9N18560 Schneider Electric
Opis
Vigi C120 - earth leakage add-on block - 4P - 300 mA - class A si
Tehnične lastnosti
| Glavno | |
| [In] rated current | 125 A |
| Serija izdelka | C120 |
| network type | AC |
| Izdelek ali sestavni del | add-on residual current devices |
| Opis polov | 4P |
| Kratko ime naprave | Vigi C120 |
| earth-leakage protection class | type A-SI |
| earth-leakage sensitivity | 300 mA |
| earth-leakage protection time delay | selective |
| Komplementarno | |
| network frequency | 50 Hz |
| Višina | 95 mm |
| mounting support | 35 mm symmetrical DIN rail |
| 9 mm pitches | 10 |
| Teža izdelka | 0.58 kg |
| Povezave - terminali | tunnel type terminals 1-35 mm² flexible tunnel type terminals 1-50 mm² rigid |
| wire stripping length | 15 mm |
| [Ui] Nazivna izolacijska trdnost | 500 V AC 50/60 Hz conforming to IEC 60947-1 |
| mounting mode | clip-on |
| mechanical durability | 20000 cycles |
| Kompatibilnostna koda | Vigi C120 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| colour | white |
| Širina | 198 mm |
| Globina | 73 mm |
| tightening torque | 3.5-3.5 N.m |
| [Ue] rated operational voltage | 230...415 V AC 50 Hz |
| product compatibility | single terminal |
| market segment | small commercial residential |
| device location in system | outgoer |
| residual current tripping technology | voltage independent |
| electrical connection to mcb | by screws |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -25-60 °C |
| IP stopnja zaščite | IP20 |
| Stopnja onesnaženosti | 3 conforming to IEC 60947-2 |
| Temperatura okoliškega zraka za skladiščenje | -40-60 °C |
| Standardi | EN 61009 |
