A9Z05440 Schneider Electric
A9Z05440 Schneider Electric
Opis
Acti 9 ID K - residual current circuit breaker - 4P - 40A - 30mA - type AC
Tehnične lastnosti
| Glavno | |
| [In] rated current | 40 A |
| Serija izdelka | Acti 9 |
| network type | AC |
| Izdelek ali sestavni del | residual current circuit breaker (RCCB) |
| product name | Acti 9 ID K |
| Skupina izdelkov | Acti 9 |
| Opis polov | 4P |
| Kratko ime naprave | ID K |
| neutral position | left |
| earth-leakage protection class | type AC |
| earth-leakage sensitivity | 30 mA |
| earth-leakage protection time delay | instantaneous |
| quality labels | OVE VDE |
| Komplementarno | |
| network frequency | 50/60 Hz |
| Višina | 81 mm |
| contact position indicator | no |
| mounting support | DIN rail |
| 9 mm pitches | 8 |
| comb busbar and distribution block compatibility | bottom: fork |
| Povezave - terminali | biconnect top or bottom 1-35 mm² rigid biconnect top or bottom 1-25 mm² flexible |
| wire stripping length | 14 mm for top or bottom connection |
| control type | toggle |
| [Ui] Nazivna izolacijska trdnost | 440 V AC 50 Hz |
| mounting mode | clip-on |
| electrical durability | AC-1: 2000 cycles |
| mechanical durability | 5000 cycles |
| Kompatibilnostna koda | ID K |
| [Uimp] rated impulse withstand voltage | 4 kV |
| colour | white |
| Širina | 72 mm |
| Globina | 68 mm |
| tightening torque | 3.5-3.5 N.m top or bottom |
| [Ue] rated operational voltage | 380...415 V AC 50 Hz |
| market segment | residential small commercial |
| device location in system | outgoer |
| residual current tripping technology | voltage independent |
| rated breaking and making capacity | Idm 500 A Im 500 A |
| surge current | 250 A |
| rated conditional short-circuit current | gL63: Inc 4.5 kA K60: Inc 6 kA |
| Okolje | |
| Temperatura okoliškega zraka za delovanje | -5-40 °C |
| IP stopnja zaščite | IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 |
| Stopnja onesnaženosti | 2 |
| Temperatura okoliškega zraka za skladiščenje | -30-70 °C |
| Standardi | EN/IEC 61008-1 |
| Elektromagnetna kompatibilnost | 8/20 µs impulse withstand, 200 A conforming to EN/IEC 61008-1 |
