MGU3.510.12 Schneider
MGU3.510.12 Schneider
Opis
Unica Top/Class - rotary dimmer - 230 VAC - 400 VA - graphite
Tehnične lastnosti
| Glavno | |
| Serija izdelka | Unica |
| Izdelek ali sestavni del | rotary dimmer |
| fixing mode | clip-in |
| [Ue] rated operational voltage | 230 V AC 50 Hz |
| Predstavitev naprave | mechanism |
| cover plate colour tint | graphite |
| aesthetic name | Unica Top - Unica Class |
| number of modules | 2 modules |
| dimmer application | inductive load fluorescent lamp with 1-10 V electronic transformer |
| Komplementarno | |
| Višina | 45 mm |
| Teža izdelka | 0.104 kg |
| Povezave - terminali | screw terminals |
| Širina | 45 mm |
| Globina | 54 mm |
| product certifications | AENOR CE |
| standards | EN 60669-2-1 |
| Material | ASA + PC: mechanism cover |
| fuse type | 4 Ah 5 x 20 mm 230 V 50 Hz |
| protection type | fuse protection |
| Označevanje | L+N |
| output current | <= 200 mA |
| clamping connection capacity | <= 2 x 2.5 mm² |
| ambient air temperature for operation | 5-30 °C |
| market segment | small commercial residential |
| embedding depth | 34 mm |
| total number of wires | 4 |
| ambient air temperature for storage | -20-60 °C |
| load type | fluorescent tube (diameter: 26-38 mm): 1 1-10 V dimmable electronic ballast - 400 VA fluorescent tube, 36 W: 10 1-10 V dimmable electronic ballast - 400 VA fluorescent tube, 2 x 16 W (diameter: 26-30 mm): 5 1-10 V dimmable electronic ballast - 400 VA external relay: 50 1-10 V electronic ballast - 400 VA |
| maximum permanent current | 0.2 A |
| dimmer control | ON/OFF push |
| Okolje | |
| IP stopnja zaščite | IP20 |
| IK stopnja zaščite | IK01 |
| environmental characteristic | liquid soap oil petrol alcohol ammonia UV resistant window-cleaning fluid acetone bleach |
| environmental health and issues | halogen free |
