VZ1L018UM20 Schneider Electric
VZ1L018UM20 Schneider Electric
Opis
line choke - 2 mH - 18 A - 1 phase - 30 W - for variable speed drive
Tehnične lastnosti
| Glavno | |
| [In] rated current | 18 A |
| Serija izdelka | Altivar |
| Izdelek ali sestavni del | line choke |
| Aplikacija naprave | reduction of current harmonics |
| Združljivost izdelkov | ATV312HU11M2 - line choke - 1 per drive ATV312HU15M2 - line choke - 1 per drive ATV312HU22M2 - line choke - 1 per drive ATV31CU11M2 - line choke - 1 per drive ATV31CU15M2 - line choke - 1 per drive ATV31CU22M2 - line choke - 1 per drive ATV32HU11M2 - line choke - 1 per drive ATV32HU15M2 - line choke - 1 per drive ATV32HU22M2 - line choke - 1 per drive LXM05D17F1 - line choke - 1 per drive LXM05D17M2 - line choke - 1 per drive LXM05D28F1 - line choke - 1 per drive LXM05D28M2 - line choke - 1 per drive LXM32.D18M2 - line choke - 1 per drive LXM32.D30M2 - line choke - 1 per drive LXM32.U90M2 - line choke - 1 per drive variable speed drive ATV320 motor: 1.1 kW 200...240 V - single phase - line choke - 1 per drive variable speed drive ATV320 motor: 1.5 kW 200...240 V - single phase - line choke - 1 per drive variable speed drive ATV320 motor: 2.2 kW 200...240 V - single phase - line choke - 1 per drive |
| value of inductance | 2 mH |
| Združljivost serije/obsega | Altivar 312 Solar Lexium 32 Altivar 312 Altivar 31C Lexium 05 Altivar Machine ATV320 Altivar 32 |
| network number of phases | single phase |
| thermal losses | 30 W |
| Komplementarno | |
| Višina | 120 mm |
| Teža izdelka | 1.99 kg |
| Širina | 85 mm |
| Globina | 105 mm |
| supply frequency | 50...60 Hz |
| maximum voltage drop at rated load | 5 % |
| Okolje | |
| IP stopnja zaščite | choke: IP00 terminals: IP20 |
| Standardi | VDE 0160 level 1 IEC 60076 (with HD398) EN 50178 |
